Quick Details
-
Brand Name:
-
Scinor
-
Material:
-
PVDF
-
Weight:
-
85kgs
-
Size:
-
2280*290*380(mm)
-
Power:
-
standard
-
Weight (KG):
-
85 kg
-
Fiber Material:
-
Polyvinylidene Fluoride (PVDF)
-
Membrane Technology:
-
TIPS
-
Membrane Configuration:
-
Hollow Fiber
-
Nominal Pore Size:
-
0.03 μm
-
Fiber I.D./O.D.:
-
0.7 mm/1.3 mm
-
Flow Configuration:
-
Outside-in
-
Housing Material:
-
U-PVC/ABS
-
Potting Material:
-
Epoxy Resin
-
Sealing Type/Material:
-
0-ring/EPDM
-
Module Specifications:
-
4", 6", 8", 9", 10", etc.
Quick Details
-
Applicable Industries:
-
Water Treatment
-
Core Components:
-
PVDF membrane
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
Scinor
-
Material:
-
PVDF
-
Weight:
-
85kgs
-
Size:
-
2280*290*380(mm)
-
Power:
-
standard
-
Weight (KG):
-
85 kg
-
Fiber Material:
-
Polyvinylidene Fluoride (PVDF)
-
Membrane Technology:
-
TIPS
-
Membrane Configuration:
-
Hollow Fiber
-
Nominal Pore Size:
-
0.03 μm
-
Fiber I.D./O.D.:
-
0.7 mm/1.3 mm
-
Flow Configuration:
-
Outside-in
-
Housing Material:
-
U-PVC/ABS
-
Potting Material:
-
Epoxy Resin
-
Sealing Type/Material:
-
0-ring/EPDM
-
Module Specifications:
-
4", 6", 8", 9", 10", etc.
| Fiber Specifications: |
|
Fiber Material |
Polyvinylidene Fluoride (PVDF) |
|
Membrane Technology |
TIPS |
|
Membrane Configuration |
Hollow Fiber |
|
Nominal Pore Size |
0.03 μm |
|
Fiber I.D./O.D. |
0.7 mm/1.3 mm |
Module Specifications
|
Flow Configuration |
Outside-in |
|
Housing Material |
U-PVC/ABS |
|
Potting Material |
Epoxy Resin |
|
Sealing Type/Material |
O-ring/EPDM |
| Feed In/Filter Out Size | JIS80A Coupling |
| Conc.Outlet Size | JIS65A Coupling |
|
Effective Area |
72 m 2 |
|
Module Volume (Water) |
50 L |
|
Weight (Water-filled/Empty) |
95/45 kg |
|
Packing Weight |
107kg |
