Quick Details
-
Brand Name:
-
Hirschmann
-
Product name:
-
Compact OpenRail Fast Ethernet Switch
-
Ports:
-
16 Ports
-
Model:
-
RS20-1600T1T1SDAUHH/HC
-
Warranty:
-
1 Year
-
Keywords:
-
Hirschmann Switch
-
Brand:
-
Hirschmann
-
Certification:
-
ce
Quick Details
-
Type:
-
Enterprise Switch
-
Model Number:
-
RS20-1600T1T1SDAUHH/HC
-
Place of Origin:
-
Germany
-
Brand Name:
-
Hirschmann
-
Product name:
-
Compact OpenRail Fast Ethernet Switch
-
Ports:
-
16 Ports
-
Model:
-
RS20-1600T1T1SDAUHH/HC
-
Warranty:
-
1 Year
-
Keywords:
-
Hirschmann Switch
-
Brand:
-
Hirschmann
-
Certification:
-
ce
Hirschmann Switch Compact OpenRail Fast Ethernet Switch 16 ports - RS20-1600T1T1SDAUHH09.0
16 port Fast-Ethernet-Switch, unmanaged, for DIN rail store-and-forward-switching, fanless design
Technical Specifications
|
Description |
16 port Fast-Ethernet-Switch, unmanaged, for DIN rail store-and-forward-switching, fanless design |
|
Part Number |
943 434-047 |
|
Port type and quantity |
16 ports in total; 1. uplink: 10/100BASE-TX, RJ45; 2. uplink: 10/100BASE-TX, RJ45; 14 x standard 10/100 BASE TX, RJ45 |
More Interfaces
|
Power supply /signaling contact |
1 x plug-in terminal block, 6-pin |
Network size - length of cable
|
Twisted pair (TP) |
0 m ... 100 m |
Network size - cascadibility
|
Line - / star topology |
any |
Power requirements
|
Current consumption at 24 V DC: |
392 mA |
|
Current consumption at 48 V DC |
196 mA |
|
Operating voltage |
12/24/48 V DC (9,6-60) V and 24 V AC (18-30) V (redundant) |
|
Power output in Btu (IT) h |
32.1 |
Ambient conditions
|
MTBF (MIL-HDBK 217F: Gb 25 ºC) |
45.5 years |
|
Operating temperature: |
0 ºC ... 60 ºC |
|
Storage/transport temperature: |
-40 ºC ... 70 ºC |
|
Relative humidity (non-condensing): |
10-95 % |
|
Protective paint on PCB |
No |
Mechanical construction
|
Dimensions (WxHxD): |
110 mm x 131 mm x 111 mm |
|
Weight: |
600 g |
|
Mounting: |
DIN Rail, |
|
Protection class: |
IP20 |
100% Brand New
We can offer the best competitive price for you !
Technical Support
1) One Year W arran ty(after our delivery date)
2)10 Years’ experience in industrial automation
3) Model selecting and double checking before shipping out
For model nos and techinical data, please feel free to contact us !
If any urgent request,please kindly contact us first.
