Quick Details
-
Application:
-
Workshop
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CANBO
-
Model Number:
-
LV801
-
Usage:
-
Motion&presence sensor
-
Technology:
-
INGENIC T31N
-
Frequency:
-
1.5GHz
-
Detection mode:
-
Moving + human figure detection (Dual mode)
-
Pixel:
-
HD 720P 1296*732
-
Installation Height:
-
6M(MAX)
-
View adjustment:
-
0-90° (expose installation) 0-45°(embedded installation)
-
Detection function:
-
human figure motion, presence, remote control,monitoring, switching
-
size:
-
86.3x69x79.5mm(expose) 129.6x82x70.7mm(embedded)
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support, Free spare parts, Return and Replacement
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation
-
Application:
-
Workshop
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CANBO
-
Model Number:
-
LV801
-
Usage:
-
Motion&presence sensor
-
Technology:
-
INGENIC T31N
-
Frequency:
-
1.5GHz
-
Detection mode:
-
Moving + human figure detection (Dual mode)
-
Pixel:
-
HD 720P 1296*732
-
Installation Height:
-
6M(MAX)
-
View adjustment:
-
0-90° (expose installation) 0-45°(embedded installation)
-
Detection function:
-
human figure motion, presence, remote control,monitoring, switching
-
size:
-
86.3x69x79.5mm(expose) 129.6x82x70.7mm(embedded)
Product Description
CNB-LV801 Tuya Smart App Security Camera Monitor Glass Sliding Door Activation Detector Visual Sensor
Camera sensor
,
r
ecognizing the human figure in the detecting area, whether in the moving or stationary state, it can also outout signals. This product can be as a motion sensor, also as a presence safety sensor.
Visual sensor, AI human figure intelligent detection, recognizing the human figure in the detecting area, whether in the moving or stationary state, it can also outout signals. This product can be as a motion sensor, also as a presence safety sensor.
Working mode switch:
Mode 1: "human figure+slight movement" mode
Press the setting button once, when you hear ONE beep voice, it will switch to mode 1: When someone enters the detection range, the sensor recognizes the human figure, door will open; When someone stays under the door, slight movements will also be sensed, door will not be closed at this time, also as safety presence function for automatic gate.
Application: High-sensitivity induction, suitable for applications that require both motion and anti-pinch functions. (Factory default setting).
Mode 2: "human figure+movement" mode
Press the setting button again, when you hear TWO beep voice, it will switch to mode 2: When someone enters the detection range, the sensor recognizes the human figure, door will open; When someone stays under the door, normal movements will be sensed, also used to automatic gates as safety presence function.
Application: Normal induction, suitable for scenes with slight disturbance, such as floating water, fish tanks, shaking plants on site.
Mode 3: "Only human figure" mode
Press the setting button again, when you hear THREE beep voice, it will switch to mode 3: When someone enters the detection range,
the door will only open if the sensor recognizes the entire human figure.
Application: It is suitable for scenes that only recognize human figure and do not need to react to other objects.
Mode 4: "only movement" mode
Press the setting button again, when you hear FOUR beep voice, it will switch to mode 4: When someone or objects enters the detection range, any movement will be recognized, and door will open.
Application: Suitable for scenes that all movement are sensed. And in the mode 4, the detection range can be adjusted freely according to your need on site. High sensitivity and high precision.
Product features
1, Adopt advanced Convolutional Neural Network, to detect and recognize the human figure, can avoid interference from strong light, vibration, flying insects, floating leaves, etc.
2, Use the video stream image acquisition technology, on the basis of ensure a certain angle of view, the sensing detection of ultra-high door can be realized, and the maximum installation height can be 6 meters.
3, It supports inserting an SD card and expanding the memory to 128G to realize all-day video monitoring; and it is convenient for users to upgrade the system without changing the hardware.
4, Built-in Wi-Fi module, which can be connected to mobile phone through external Wi-Fi network or mobile phone hotspot.
5, Equipped with the global AI+LOT Internet of Things platform--"TUYA", the detecting area size can be set through the APP, and remote monitoring and remote opening of the door can be realized by mobile phones.
6, With single axis eagle eyes design, flexibly to adjust the view angles, and the detecting areas.
7, After power on, it will automatically enter the AI human figure detection and recognition mode, without background learning.
8, Built-in microphone, real-time simultaneous monitoring.
Specification
|
ITEM
|
Image Recognition Sensor
|
|
BRAND
|
CANBO
|
|
MODEL
|
LV801
|
|
Main processor
|
INGENIC T31N
|
|
Main frequency
|
1.5GHz
|
|
Detection mode
|
Moving + human figure detection (Dual mode)
|
|
Pixel
|
HD 720P 1296*732
|
|
Response speed
|
50ms
|
|
Monitor storage
|
TF card in FAT32 format, maximum 128GB memory
|
|
View adjustment
|
0-90° (expose installation) 0-45°(embedded installation)
|
|
Network distance
|
10-30 meters (dependin on the strength of Wi-Fi on site)
|
|
Detection function
|
human figure motion, presence, remote control opening, monitoring, period function switching
|
|
Signal output
|
Relay ON, CN
|
|
Power supply
|
AC/DC 12-36V
|
|
Standby comsumption
|
60mA ± 30mA
|
|
Installation methods
|
Expose or embedded installation on the door head, wall, and ceiling
|
|
External dimension
|
86.3x69x79.5mm(expose) 129.6x82x70.7mm(embedded)
|
|
Installation height
|
≤ 6 meters (It can be installed higher if the installation inclination can be guaranteed)
|
Details Images
Packing & Delivery
Packing:
poly bag + PE foam + inner box + outer box, screws will be packed into a zipcode bag.
(Maybe there will be some differences in the way of packing for different models of products )
