Quick Details
-
Storage Type:
-
lead acid battery
-
The charging ratio:
-
6V 12V 24V
-
The discharge rate:
-
12 250ah
-
Battery Size:
-
520*268*220, 12V 200Ah
-
Brand Name:
-
Pnergy solar
-
Model Number:
-
6GFM250
-
Place of Origin:
-
Anhui, China
-
Weight:
-
68kgs
-
OEM order:
-
Acceptable
-
Color:
-
black/white
-
Certification:
-
Rohs CE
-
Product name:
-
GEL Battery
-
Voltage:
-
12Volt
-
Usage:
-
Slolar Energy System
-
Capacity:
-
200Ah ~ 300Ah
Quick Details
-
Chargeable:
-
Yes
-
Battery Type:
-
Gel
-
Cycle Life:
-
2 years
-
Storage Type:
-
lead acid battery
-
The charging ratio:
-
6V 12V 24V
-
The discharge rate:
-
12 250ah
-
Battery Size:
-
520*268*220, 12V 200Ah
-
Brand Name:
-
Pnergy solar
-
Model Number:
-
6GFM250
-
Place of Origin:
-
Anhui, China
-
Weight:
-
68kgs
-
OEM order:
-
Acceptable
-
Color:
-
black/white
-
Certification:
-
Rohs CE
-
Product name:
-
GEL Battery
-
Voltage:
-
12Volt
-
Usage:
-
Slolar Energy System
-
Capacity:
-
200Ah ~ 300Ah
Product Description
Key Features:
*Gelled electrolyte made by mixing sulfuric acid with silica fume.*High rate discharge performance due to tight assembly
technology
*Strong heat dissipation and wide operating temperature range
*Avoid acid mist being separated out , environment friendliness
*Efficient venting system release excessive gas automatically
Applications:
*EPS and UPS battery backup
*Solar and wind energy storage system
*Telecommunication Equipment
*Power plant and transmission system
*Signal system , emergency lighting system , security system
*Gelled electrolyte made by mixing sulfuric acid with silica fume.*High rate discharge performance due to tight assembly
technology
*Strong heat dissipation and wide operating temperature range
*Avoid acid mist being separated out , environment friendliness
*Efficient venting system release excessive gas automatically
Applications:
*EPS and UPS battery backup
*Solar and wind energy storage system
*Telecommunication Equipment
*Power plant and transmission system
*Signal system , emergency lighting system , security system
Specification
|
Rated Voltage
|
12V
|
|
Numbers of cells
|
6 Cells
|
|
Capacity
|
250Ah@10hr-rate to 1.80V per cell @25°C
|
|
Weight
|
70kg
|
|
Internal Resistance
|
Approx. 2.5mΩ
|
|
Terminal
|
F1 / F2
|
|
Max. Discharge Current
|
3750A(5s)
|
|
Short Circuit Current
|
12500A
|
|
Max. Charging Current
|
62.5A
|
|
Reference Capacity
|
C10 250AH/C3 181.0H/C1 136.6AH
|
|
Design Life
|
10~15 years
|
|
Float Charging Voltage
|
13.6 V~13.8 V @ 25°C, Temperature Compensation: -20mV/°C/Cell
|
|
Cycle Use Voltage
|
14.4 V~14.9 V @ 25°C, Temperature Compensation: -30mV/°C/Cell
|
|
Operating Temperature Range
|
Discharge: -15°C~50°C, Charge: 0°C~40°C, Storage: -15°C~40°C
|
|
Normal Operating Temperature Range
|
25°C±5°C
|
|
Self Discharge
|
Less than 3% at 25°C per month
|
|
Container Material
|
A.B.S. UL94-HB, UL94-V0 Optional.
|
|
Pre-sales project design
|
Y
|
|
|
|
