modern cheap prefab homes new fast house concrete prefab light steel villa

modern cheap prefab homes new fast house concrete prefab light steel villa

FOB Reference Price: Get Latest Price

≥50 Square meters

US $180

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Color:: customization

Function:: Residence

External wall moisture:: one-way breathable breath paper

Exterior wall structure:: 12mm OSB board

External wall insulation:: B1 grade extruded board or wood plastic board

Quick Details

Place of Origin:: Henan, China

Assembly method:: assembled

Size:: customization

Color:: customization

Function:: Residence

External wall moisture:: one-way breathable breath paper

Exterior wall structure:: 12mm OSB board

External wall insulation:: B1 grade extruded board or wood plastic board

Products Description

modern cheap prefab homes new fast house concrete prefab light steel villa

Light steel villa, also known as light steel structure housing, its main material is by hot dip galvanized steel strip by cold rolling technology synthesis of light steel keel, after accurate calculation plus auxiliary support and combination, play a reasonable bearing capacity, to replace the traditional housing.

Main Features

1) Light steel structure parts manufacturing factory and mechanization, high degree of commercialization.

2) Site construction speed, will not affect the nearby residents, conducive to civilized construction.

3) The steel structure building is the environmental protection type sustainable development product.

4) Light weight, good shock resistance, plate can be reused.

5) Safety is good, permanent building and color board room activity room has essential distinction.

6)The service life of the house has reached the national standard of 100 years.

Number	Part Name	Material
1	Light steel structure keel	G550 Z275 Australian standard keel thickness 0.8
2	Exterior wall structure	12mm OSB board
3	Exterior wall waterproof	One-way breathable breath paper
4	External wall insulation	B1 grade extruded board (fireproof material)
5	Exterior finish	Metal carved board or wood grain cement fiber outer board, real stone paint finish (texture exterior wall paint) and local culture stone
6	Wall insulation	A1 grade non-combustible 75mm thick rock wool board
7	Interior wall structure	9mm OSB board (paper gypsum board) and partial calcium silicate board (cement fiber board)
8	Interior wall decoration	Interior paint or wallpaper
9	Indoor ceiling	Living room level two, the other level
10	Water and electricity	Brand switch, wire, pipeline (excluding lamp sanitary ware)
11	Indoor floor	Wooden floor or floor tile
12	Outdoor step	Marble
13	Entry door	Security door
14	Outdoor window	Ordinary aluminum alloy window (hollow double glazing)
15	Interior door	Paint-free solid wood door
16	Eaves	PVC guard or textured exterior paint
17	Roof structure	12mm OSB board
18	Roof waterproofing	Self-adhesive waterproofing membrane
19	Roof tile	Metal tile, resin tile or asphalt tile

Details Images

Structural materials

Light steel keel： The C-type and U-type keels of double-sided galvanized 275g/cold-rolled sheet are used as light steel structural materials.

OSB board： The OSB boards used by our company are all imported from Canada, and the formaldehyde emission is lower than Euro E1 grade.
Gypsum board： With gypsum as the main raw material, the core material is composed of lightweight aggregate, fiber reinforced material and admixture, which is firmly bonded with paper protection.

Thermal insulation material

Rock wool： a. Class A1 non-combustible material b. Density ρ=800～1100kg/m3. c. Thermal conductivity ≤ 0.044W/cm.k d. Heat resistance ≥ 650 degrees e. Excellent sound insulation

Fiberglass cotton： a. Class A1 non-combustible materials b. No smell, environmental protection and non-toxic c. Thermal conductivity ≤ 0.03W/cm.k d. The heat resistance is ≥ 700 degrees. Porous structure, good recovery, not afraid of any shock vibration

Extruded plate： a. High thermal resistance, the structure closed porosity is more than 99%, and the 20mm thick insulation effect is equivalent to 120mm thick cement perlite. b. High compressive strength and impact resistance. c. Excellent water repellency and moisture resistance d. Stability, corrosion resistance, no decomposition, mildew, no toxic substances e. The production process does not produce any industrial pollution, and is an environmentally friendly building material.

waterproof material

waterproof breathable film： The polyethylene microporous film is used as an intermediate layer, and the two sides are combined by a hot melt direct pressing process, and the middle layer is a main waterproof layer.

Self-adhesive waterproofing membrane： It has strong bonding performance and self-healing properties, and is suitable for cold construction in high and low temperature environments.

Waterproof coating: easy to construct, easy to take, suitable for all kinds of base building, uniform and no dead angle, diversified colors, smooth coating surface.

Exterior wall decoration material

Metal carved plate： The high-quality color relief veneer metal plate with special coating on the surface, the middle layer is the heat-resistant layer of the hard high-density polyurethane insulation section, and the bottom layer is the aluminum foil protection layer for heat insulation and moisture resistance.

PVC outer wall hanging board: It has the characteristics of oxidation resistance, corrosion resistance, low price, energy saving and environmental protection, convenient construction and little influence by seasonal changes.

Wood grain cement fiber hanging board: It has the characteristics of durability, light weight, heat insulation, anti-freezing, sound absorption, fireproof, mildewproof and anti-ant

Exterior wall decoration material

Cement fiber decorative board: light weight, fireproof, waterproof, mildewproof, heatstroke prevention, anti-ant, heat insulation, sound insulation, impact resistance, acid and alkali resistance, aging resistance, frost resistance, green environmental protection, is a collection of functionality, decorative As a high-end exterior wall decoration material.

Artificial culture stone: The high-grade artificial culture stone has the characteristics of environmental protection, energy saving, light texture, rich color, mildew and non-combustibility, good anti-freezing property and easy installation.

Roofing material

Color stone metal tile: light and high strength, strong and durable, easy to install.

Asphalt shingles: It has good waterproof and decorative functions, rich colors, various forms and simple construction.

Color steel profiled tile: It has the characteristics of light weight, high strength, rainproof, long life, rich color, convenient construction and maintenance-free. It has been widely used.

Terracotta tiles: rich in color, not easy to lose color, fireproof and long life, dense enamel surface, can prevent bacteria and dirt from entering and entering, no odor and no release of harmful substances, easy to clean without maintenance.

Installation Instructions

The integration of light steel housing all building materials can realize the factory batch production and prefabricated, high mechanization degree, the site didn't wet homework, truly achieve residential industrialization, the whole construction process environment environmental protection, design is determined, a house of 300 square meters from production to installation is complete, need only a month a specially customized for you.

Product packaging

Our Advantages

1.Your inquiry of our will be replied in 24 hours.
2. Good quality product, quick delivery time, competitive price, strong packing.
3.According to your needs, we can produce, including size / color / door and window position.
4.We will provide product installation drawings and installation videos.
5.Our engineers and workers can be sent abroad for guidance and installation.
6.10 professional engineers conduct consulting services.
7. We have enthusiastic and energetic sales force who can speak English fluently.
