Quick Details
-
Weight:
-
120KG
-
Product name:
-
Solar Inverter Battery
-
Nominal Voltage:
-
51.2V
-
Maximum Charging Current:
-
200A (1C)
-
Cycle life (80%DOD):
-
6000 times
-
Battery Size:
-
18650,26500,Lifepo4 lithium Battery
-
Model:
-
Phosphate Battery For Energy Storage
-
Discharging Temperature:
-
-30~60℃
-
Keywords:
-
Rechargeble Lipo Battery
-
Material:
-
Metal Case
-
Battery cell:
-
Pack Battery
Quick Details
-
Brand Name:
-
TF
-
Place of Origin:
-
Guangdong, China
-
Dimension (L*W*H):
-
610*440*255mm
-
Weight:
-
120KG
-
Product name:
-
Solar Inverter Battery
-
Nominal Voltage:
-
51.2V
-
Maximum Charging Current:
-
200A (1C)
-
Cycle life (80%DOD):
-
6000 times
-
Battery Size:
-
18650,26500,Lifepo4 lithium Battery
-
Model:
-
Phosphate Battery For Energy Storage
-
Discharging Temperature:
-
-30~60℃
-
Keywords:
-
Rechargeble Lipo Battery
-
Material:
-
Metal Case
-
Battery cell:
-
Pack Battery
Free Shipping 48V 5Kw Lithium iron Phosphate Battery 5Kwh Solar LiFePO4 Pack Battery 48V 100Ah Energy Storage Battery
Why TANFON 48V lifepo4 battery
Battery is with digital display which allow users to monitor voltage of each serial of cells, battery’s rated voltage and capacity, temperatures and BMS parameters etc.
Max 32 In Parallel
Up to 32pcs can be connected in parallel add/remove batteries online without going offline. It can meet the requirements of redundant system design, and the failure of a single module will not affect others, achieving ultra-high online rate.
10KWh supports 32pcs capacity up to 320KWh.
15KWh supports 32pcs capacity up to 480KWh .
Customers can expand the capacity later according to the power demand of the family.
Rack-Mounted LiFePO4
51.2V 10.24/15.36KWH Solar Battery
1. 51.2V 200/300AH LiFePO4 Battery Module.
2. Support samrt communication function RS485/ CAN bus and Compatible with global mainstream inverters brand
3.The internal material is designed with stainless steel material, which has low internal resistance, enhanced heat dissipation, and good stability to protect the battery cell from external damage
4. High energy/power density, density, energy/liter density is 327.1Wh/L, power density is 314KW/m³, easy to achieve dense design.
More available energy up to 100% More throughput lifetime up to 25.2MWh Up to 96% round-trip efficiency (discharge capacity/charge capacity) data from the
laboratory Support super fast charging, 5-95% window charging can be completed within 60 minutes.
|
Model No
|
LFP4850
|
LFP48100
|
LFP48150
|
LFP48200
|
LFP48300
|
||||
|
Voltage
|
48 V/51.2V
|
48 V/51.2V
|
48 V/51.2V
|
48 V/51.2V
|
48 V/51.2V
|
||||
|
Capacity
|
50Ah
|
100Ah
|
150Ah
|
200Ah
|
300Ah
|
||||
|
Energy
|
2.4KWH
|
5.12KWH
|
7.68KWH
|
10.24KWH
|
15.36KWH
|
||||
|
Operation voltage
|
35.25-58.4 Vdc
|
37.6-58.4Vdc
|
37.6-58.4Vdc
|
37.6-58.4Vdc
|
37.6-58.4Vdc
|
||||
|
Max.charging voltage
|
58.4Vdc
|
58.4 Vdc
|
58.4 Vdc
|
58.4 Vdc
|
58.4 Vdc
|
||||
|
Max.charging and discharging current
|
50A
|
100A
|
100A
|
100A
|
100A
|
||||
|
Max Power
|
2400W
|
5120W
|
7680W
|
10240W
|
15360W
|
||||
|
Life time(25°C)
|
10 years
|
|
|
|
|
||||
|
Life cycles(80% DOD, 25°C)
|
6000+ Cycles
|
|
|
|
|
||||
|
Storage time / temperature
|
5 months @ 25°C; 3 months @ 35°C; 1 month @ 45°C
|
|
|
|
|
||||
|
Operation temperature
|
-20°C to 60°C @60+/-25% Relative Humidity
|
|
|
|
|
||||
|
Storage temperature
|
0°C to 45°C @60+/-25% Relative Humidity
|
|
|
|
|
||||
|
Enclosure protection rating
|
IP65
|
|
|
|
|
||||
|
Dimensions(L×W×H)mm
|
480*440*160
|
480*440*160
|
480*440*200
|
480*440*255
|
480*570*255
|
||||
|
Weight
|
35KG
|
45KG
|
60KG
|
85KG
|
120KG
|
||||
FAQ：
Q1: What’s the life of TANOFN wall mounted battery?
A: 80% DOD more than 6000 cycles.
Q2: Can the battery be connect in parallel?
A: Yes,support in parallel for more than 32pcs.
Q3: Can the wall mounted battery work with my hybrid inverter?
A: Yes, the wall mounted battery suitable for all off grid and hybrid inverter.
Q4: What’s the warranty of wall mounted battery?
A: 10 years,we support extended warranty services.
Q5: What is the battery output power?
A: 10KW Per battery.
Q6: Does the wall mounted battery including inverter?
A: No, is battery only, so it is more flexible to work with different brand of inverter preferred by customer.
Q7: Does the wall mounted battery with communication function?
A: Yes, TANOFN wall mounted battery with RS485&CAN communication with PC and smart LCD for monitoring.
