Wanglink 10/100/1000Mbps Industrial Ethernet Switch 2 SC Fiber 4 RJ45 Port Support Manageable Cascade Connected

Wanglink 10/100/1000Mbps Industrial Ethernet Switch 2 SC Fiber 4 RJ45 Port Support Manageable Cascade Connected

FOB Reference Price: Get Latest Price

≥100 Pieces

US $72.9

≥500 Pieces

US $67.9

≥1000 Pieces

US $60.9

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Brand Name:: Wanglink

Use:: FTTH, FTTH,FTTX,FTTP

Warranty Time:: 1 Year

Model:: WOR-GYHW924-SFP

Network:: Wired LAN

Certification:: CE RoHS FCC

Wavelength:: 850nm/1310nm/1550nm

Application:: Network

Input voltage:: 24V DC (18-36v DC)

Working temperature:: -40 ℃~80 ℃

Storage temperature:: -40~ 85"C

Working humidity:: 10~ 90%

Quick Details

Type:: Fiber optic media converter

Model Number:: WOR-GYHW924-SFP

Place of Origin:: Guangdong, China

Brand Name:: Wanglink

Use:: FTTH, FTTH,FTTX,FTTP

Warranty Time:: 1 Year

Model:: WOR-GYHW924-SFP

Network:: Wired LAN

Certification:: CE RoHS FCC

Wavelength:: 850nm/1310nm/1550nm

Application:: Network

Input voltage:: 24V DC (18-36v DC)

Working temperature:: -40 ℃~80 ℃

Storage temperature:: -40~ 85"C

Working humidity:: 10~ 90%

Product Description

Wanglink 10/100/1000Mbps Industrial Ethernet Switch 2 SC Fiber 4 RJ45 Port Support Manageable Cascade Connected

Wanglink WOR-GYHW924-SFP Managed Industrial Network switch have 2 port 1000M SFP fiber, 4 port 10/100/1000M adaptive RJ45. Adopted Ring network technology(network fault diagnosis and self-recovery time <20ms), users can easily set up redundant ring network to increase network reliability. SNMPv3, IEEE 802.1X, HTTPS and SSH standard, better enhanced network security. Industrial IP40 Protection design, -40~+75℃ Wide operating temperature can meet the requirements of various industrial sites, which has been widely used in electricity, hydraulic engineering, rail transit and other fields.

Product Features

1) Industrial Ethernet series, Special designed for harsh industrial environments
2) Support command line interface (CLI), can easy and fast configuration of main management functions
3) Support IEEE 1588 PTP V2, can achieve accurate network time synchronization
4) DHCP Option 82 is used to assign IP addresses with different ways and strategies
5) Support "ring" protocol(network fault diagnosis and self-recovery time <20ms) and and RSTP/STP/MSTP Ethernet switch redundancy
technology
6) Support IGMP Snooping and GMRP protocol
7) Support for port-based VLAN, IEEE 802.1q VLAN and GVRP protocols, can make a simple network planning
8) Support port mirroring
9) Support Ethernet/IP and Modbus/TCP protocol, which used for equipment management and control
10) Support multicast and broadcast storm control
11) Bandwidth Management:Support port Multiplier function, port speed limit and broadcast storm suppression
12) Support QoS and ToS/DiffServ, which is used for flow control and management
13) Support link aggregation and optimize bandwidth utilization
14) Support SNMPv3, IEEE 802.1X, HTTP and SSH standard, better enhanced
15) Support SNMPv1/v2c/v3 different security levels network security network management
16) Support TACACS+
17)Adopted RMON technology, can effectively improve network monitoring and forecasting ability
18) Support bandwidth management to ensure network stability
19) Support port locking based on MAC address to prevent illegal intrusion
20) Through E-mail and relay output, automatic alarm
21) Reset:Supports restart and restore default configuration

Product Specification

Product Name	Wanglink 10/100/1000Mbps Industrial Ethernet Switch 2 SC Fiber 4 RJ45 Port Support Manageable Cascade Connected
Material	Iron,IP40 protection
Interface	MSC port :1000Base-x SC interface Gigabit port :10/1001000 base-t (X) adaptive Ethernet RJ45 interface Console: r5-232 (RU45 connector)
Power requirements	Input voltage: 24V DC (18-36v DC), redundant double power input Access terminal: 6 core 5.08mm interval insertion terminal Power current <0.5A at 24VDC Overload protection: support Reverse protection: support Redundancy protection: support
Color	Black, Blue
Environment	Working temperature: -40 ℃~80 ℃ Storage temperature -40~ 85"C Working humidity: 10~ 90%, non-con densingStorage humidity 10% - 95%, non- condensing
Standard	The IEEE 802.3 I The IEEE 802.3 z The IEEE 802.3 u The IEEE 802.3 ab IEEE 802.3x flow control The IEEE 802.1 D - 2004 STP The IEEE 802.1 w Rapid STP The IEEE 802.1 Q VLAN Tagging TEEE 802.1 p Cos IEEE 802.1 X authentication IEEE 802.3 AD link aggregation
Mechanical characteristics	Case: aluminum machine design, no fan, IP40 protection grade Size: 13910948mm Installation: guide rail mounting/wall mounting
Protocol	Op-ring, IGMPv1 v2, GVRP, SNMP VI/V2C/V3, DHCP Client TFTP. SMTP, RMON, HTTP, HTTPS, Telnet, Syslog, gvrpssh-snmp Inform, LLDP, SNTP Senver/Client, PVLAN
MIB	MIB-II . Ethemet-Like MIB. P-BRIDGE MIB , Q- BRIDGE MßBBridge MIB , RSTP MIB , RMON MIB Group1.2.3.9
Exchange properties	Priority queue :4 VLAN number: 256 VLAN ID: 1-4094 Number of multicast groups: 256 The MAC table: 8 k Middle zone :1Mbit Packet forwarding rate: 5.3Mpps Exchange delay: ≤5μ
Alarm output	One way relay alarm output: support IP/MAC conflict, power, interface and ring alarm
Dimension	13910948mm
Gross Weight	1.06KG
Installation	Installation: Din-Rail mounting, Wall mounting
Warranty	1 Year
