100% Virgin Material Waterproof Smooth HDPE Geomembrane for Agriculture/Dam/Landfill/Tailing Dam/Reservoir

100% Virgin Material Waterproof Smooth HDPE Geomembrane for Agriculture/Dam/Landfill/Tailing Dam/Reservoir

FOB Reference Price: Get Latest Price

≥1000 Square meters

US $0.56

≥5000 Square meters

US $0.45

≥50000 Square meters

US $0.25

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Application:: pond liner,fish farming

Design Style:: Industrial

Place of Origin:: Shandong, China

Brand Name:: DK

Model Number:: DK-GM

Product Name:: HDPE Geomembrane Liner

Color:: Black White Blue Green (customized)

Material:: HDPE LDPE LLDPE EPDM EVA

Thickness:: 0.1-3.0mm

Length:: Client's Requirement

Width:: 1m~8m

Standard:: ASTM GRI-GM13

Surface:: Smooth surface or Textured Surface

MOQ:: 1000m2

Density:: 0.94g/cm3

Quick Details

Warranty:: 3 years

After-sale Service:: Online technical support

Project Solution Capability:: Others

Application:: pond liner,fish farming

Design Style:: Industrial

Place of Origin:: Shandong, China

Brand Name:: DK

Model Number:: DK-GM

Product Name:: HDPE Geomembrane Liner

Color:: Black White Blue Green (customized)

Material:: HDPE LDPE LLDPE EPDM EVA

Thickness:: 0.1-3.0mm

Length:: Client's Requirement

Width:: 1m~8m

Standard:: ASTM GRI-GM13

Surface:: Smooth surface or Textured Surface

MOQ:: 1000m2

Density:: 0.94g/cm3

Products Description

HDPE Geomembrane is made of high-density polyethylene resin particles as raw material and produced by three-layer co-extrusion blow molding technology. It is a 100% waterproof material.

Product	HDPE/LDPE/LLDPE/PVC/EPDM Geomembrane
Thickness	0.25mm	0.3mm	0.5mm	0.75mm
		0.8mm	1.0mm	1.2mm	1.5mm
		1.75mm	2.0mm	2.5mm	3.0mm

Thickness	Smooth surface 0.2mm-3.0mm, textured surface 1.0mm-2.0mm
Width	Smooth surface 1m-8m, textured surface 4m-8m
Length	30m-200m/roll or as requested
Material	HDPE, LDPE, LLDPE, PVC,EPDM
Color	Black, blue, white, green
Surface	Smooth surface, single surface textured,dual surfaces textured

Item

Index

Thickness (mm)

0.30

0.50

0.75

1.00

1.25

1.50

2.00

2.50

3.00

Density ( g/cm3)

≧0.940

Tensile yield strength (N/mm)

≧4

≧7

≧10

≧13

≧16

≧20

≧26

≧33

≧40

Tensile fracture strength (N/mm)

≧6

≧10

≧15

≧20

≧25

≧30

≧40

≧50

≧60

Elongation at yield (%)

≧11

Elongation at break (%)

≧600

Right-angle tear load (N)

≧34

≧56

≧84

≧115

≧140

≧170

≧225

≧280

≧340

Puncture strength (N)

≧72

≧120

≧180

≧240

≧300

≧360

≧480

≧600

≧720

Carbon black content (%)

2.0~3.0

Product Features

1. Good physical and mechanic performance.

2. High tearing resistance, strong deformation adptability.
3. Corrosion resistance, aging resistance.
4. Good adaptability to high and low temperature, non-toxicity, long service life.
5. Good waterproof, drainage, anti-seepage and damp proof effects.
6. Complete width and thickness specifications, low cost and easy installation.

Product Application

HDPE geomembrane liner is widely used for canal, aquaculture, irrigation ponds and remediation liners, other liner applications include landfills, waste water treatment lagoons, oil and gas exploration, power plants, etc al. Aquaculture. Geomembrane liners can be used as fish ponds, shrimp pond and other aquacultures. Landfills. Bottom landfill liner, landfill sealing cover, leachate regulating pool liner, etc. Water Treatment System. Smooth Geomembrane is applied to the adjustment of the power plant and sewage treatment pool or water treatment system. Mining. HDPE Geomembrane is applied for mining industry as washing pool, pool heap leaching, heap yard, dissolving tank, storage tank, the bottom of the tailing seepage control, etc. Other Applications. Environment protection and sanitation, water conservancy, municipal projects, landscaping, petrochemical industry, salt industry, agriculture, etc.
