Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
AOE
-
Model Number:
-
V1200
-
Focal Length:
-
Bandwithd 4nm
-
Wavelength Range:
-
320-1020nm
-
Display:
-
Color LCD
-
Model name:
-
v1200
-
Wavelength accuracy:
-
±1.0nm
-
Spectral bandwidth:
-
4nm
-
Optical System:
-
Single beam,Grating 1200lines/mm
-
Stray light:
-
≤0.2%T@360nm,220nm
-
Wavelength repeatability:
-
≤0.5nm
-
Photometric Range:
-
0~200%T,-0.301-3.0A
-
Detector:
-
Silicon Photodiode
-
Noise:
-
0.001A
Quick Details
-
Warranty:
-
2 years
-
Size:
-
44*39*18cm
-
Weight:
-
9KG
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
AOE
-
Model Number:
-
V1200
-
Focal Length:
-
Bandwithd 4nm
-
Wavelength Range:
-
320-1020nm
-
Display:
-
Color LCD
-
Model name:
-
v1200
-
Wavelength accuracy:
-
±1.0nm
-
Spectral bandwidth:
-
4nm
-
Optical System:
-
Single beam,Grating 1200lines/mm
-
Stray light:
-
≤0.2%T@360nm,220nm
-
Wavelength repeatability:
-
≤0.5nm
-
Photometric Range:
-
0~200%T,-0.301-3.0A
-
Detector:
-
Silicon Photodiode
-
Noise:
-
0.001A
Features:
1, Large LCD screen (128*64 Dots) with saving standard curve function
2, Imported & Environmental Deuterium lamp, preventing from Ozone inhalation
3, Adopted high-class grating with wholly hermetic light path design, to ensure the instrument has the super low stray light
4, Real-time monitoring the lifetime of Deuterium lamp and Tungsten lamp with advanced system
5, Pre-aligned design ensures the user can change lamps conveniently
6, Wavelength calibration, wavelength setting, change lamp source and dark current calibration automatically
7, With Si02 coating optical mirror, reducing the pollution from outside fully
8, Optional PC Software to expand the applications to Quantitative, Multi-Wavelength and Kinetics
9, Widely used for Organic chemistry, Inorganic chemistry, Life sciences, foods, Medicine and health, Agriculture, Geology, Metallurgy and Environment etc. fields
Functions:
1. Photometry
Test Abs., Transmittance by fixed wavelength
2. Quantitative
a. C Mode: EstablishC=K*A curve, test sample concentration
b. F Mode: Establish A=K1*C+K0, test sample concentration
Specifications:
|
Model |
V-1200 |
|
Optical System |
Single Beam, Grating 1200 lines/mm |
|
Wavelength Range |
320-1000nm |
|
Spectral Bandwidth |
4nm |
|
Wavelength Accuracy |
± 1.5nm |
|
Wavelength Repeatability |
≤ 0.5nm |
|
Photometric Accuracy |
± 0.002A (0-0.5Abs), ± 0.004A (0.5-1.0Abs), ± 0.5% T (0-100% T) |
|
Photometric Repeatability |
0.001Abs (0-0.5Abs), 0.002Abs (0.5-1.0Abs), ≤ 0.2% T (0-100% T) |
|
Stray Light |
≤ 0.2 % T @ 360nm |
|
Stability |
± 0.002A / h @ 500nm |
|
Noise |
± 0.001A |
|
Display |
128*64 Dots LCD |
|
Photometric Mode |
T, A, C, E |
|
Photometric Range |
0-200%T,-0.301-3.0A |
|
Detector |
Silicon Photodiode |
|
Light Source |
Tungsten Lamp |
|
Input |
Membrane Keypad |
|
Output |
Parallel Print,USB1.0 |
|
Compartment |
Solid Sample Holder, Micro Cell Holder, 10-100mm Cell Holder |
Packing: Standard Carton with Wrapping film
Shiping: By air, sea and express.
Super-long warranty: 2-Year International Warranty.
After-Sale Service: Perfect after-sale service from our factory.
