Quick Details
-
Model Number:
-
XF-1,XF-3,XF-302
-
Max. Current:
-
15A
-
Contact form:
-
1C
-
Contact resistance:
-
25mΩ
-
Insulation resistance:
-
Above 100MΩ DC500V
-
Withstand voltage:
-
≥2000VAC
-
Mechanical Life:
-
1,000,000 times above
-
Electrical Life:
-
100,000 times above
-
Operating temperature:
-
-20~+70 degree
-
Operating Humidity:
-
≤85%
Quick Details
-
Max. Voltage:
-
250VAC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
XURUI
-
Model Number:
-
XF-1,XF-3,XF-302
-
Max. Current:
-
15A
-
Contact form:
-
1C
-
Contact resistance:
-
25mΩ
-
Insulation resistance:
-
Above 100MΩ DC500V
-
Withstand voltage:
-
≥2000VAC
-
Mechanical Life:
-
1,000,000 times above
-
Electrical Life:
-
100,000 times above
-
Operating temperature:
-
-20~+70 degree
-
Operating Humidity:
-
≤85%
Characteristics and Using:
Application attentions:
Contact Forms:
Technical specification:
|
Item |
Specification |
|
Model Name |
XF-502B |
|
Rating |
15A 250VAC |
|
Contact |
1C |
|
Material of Rind |
Aluminum |
|
Insulation resistance |
≥100MΩ |
|
Contact resistance |
≤25mΩ |
|
Withstand voltage |
2000VAC |
|
Electrical life |
≥100,000 |
|
Protection degree |
IP65 |
|
Temperature |
-25-75°C |
|
Humidity |
<85% |
XF-1 Dimension:
XF-3 Dimension:
XF-302 Dimension:
