Quick Details
-
Keyword:
-
Sip Panel House Kit
-
Size:
-
Standard 20ft shipping container size
-
Color:
-
White, Customer made if the quantity is large
-
Structure:
-
Galvanized steel frame with marine paint
-
Insulation:
-
PU, Rockwool or Neopor EPS
-
Window:
-
aluminum oor Pvc
-
Door:
-
Steel Cleanroom Door
-
Floor:
-
Vinyl Sheet on Plywood or Cement Board
-
Lifespan:
-
30 Years
-
Name:
-
Foldable High Quality Easy Assembly Sip Panel House Kit
Quick Details
-
Place of Origin:
-
Beijing, China
-
Brand Name:
-
Housespace
-
Model Number:
-
custom-made
-
Keyword:
-
Sip Panel House Kit
-
Size:
-
Standard 20ft shipping container size
-
Color:
-
White, Customer made if the quantity is large
-
Structure:
-
Galvanized steel frame with marine paint
-
Insulation:
-
PU, Rockwool or Neopor EPS
-
Window:
-
aluminum oor Pvc
-
Door:
-
Steel Cleanroom Door
-
Floor:
-
Vinyl Sheet on Plywood or Cement Board
-
Lifespan:
-
30 Years
-
Name:
-
Foldable High Quality Easy Assembly Sip Panel House Kit
Foldable High Quality Easy Assembly Sip Panel House Kit
Product Features:
Dimension(mm)&Weight(kg) of
Foldable High Quality Easy Assembly Sip Panel House Kit
|
Type |
External |
Internal |
Weight (kg) |
|||||
|
Length |
Width |
Height (package) |
Height (assembled) |
Length |
Width |
Height |
||
|
20’ |
6055 |
2435 |
648/864 |
2591/2790 |
5860 |
2240 |
2500 |
from 1850 |
Floor of Foldable High Quality Easy Assembly Sip Panel House Kit :
|
Steel frame |
- made from cold rolled, welded steel profiles, 4 mm thick |
|
- 4 corner casts, welded |
|
|
- 2 fork lift pockets (except 30’) - distance 1200mm (internal clearance of fork lift pockets: 240×80 mm) |
|
|
- steel cross members, thickness=2mm |
|
|
Insulation |
- 100 mm thick Rock Wool |
|
Subfloor |
- 0.5mm thick, galvanized steel sheet |
|
Floor |
- 18mm plywood board |
|
- 1.8mm PVC floor - flammability class B1 - hardly combustible - smoke density class Q1 - low smoke emission - wear resistance factor: T level |
Roof
|
Steel frame |
- made from cold rolled, welded steel profiles, 3mm thick |
|
- 4 corner casts, welded |
|
|
- steel cross members, thickness=2mm |
|
|
Roof cover |
- 0.5mm thick, galvanized steel sheet - 360 degree seaming at joint of roof panels |
|
Insulation |
- 100 mm thick Rock Wool |
|
Ceiling |
- 10 mm chipboard (V 20), laminated on both sides, white - the chipboard complies with the emission value E1 |
|
CEE connector |
- sunken in frame on short end side |
Insulation of
Foldable High Quality Easy Assembly Sip Panel House Kit
|
Rockwool |
- density:120kg/m3 |
|
- flammability class A- non combustible - smoke density class Q1 - low smoke emission |
|
|
- certificated: CE & GL |
|
|
Neopor R |
- density:18kg/m3 |
|
- flammability class B1- non combustible - smoke density class Q1 - low smoke emission |
|
|
- certificated: CE & GL |
Coatings (Optional) of
Foldable High Quality Easy Assembly Sip Panel House Kit
|
DecoCoating |
Special coating can be applied on top of sandwich wall panel and make the external wall surface looks like plastering finishes or timber finishes. That makes the container house cozy and less industry look. |
Layout of Foldable High Quality Easy Assembly Sip Panel House Kit :
Assembly Process:
Easy to be Assemble and disassemble. Four workers can complete one unit in half day.
Packing and Transportation:
From our factory to overseas client, there are two ways to delivery the houses. If your port can accept SOC (Shipper’s Owned Container), 4 standard cabins can be packed as a 20ft container and shipped naked. If can not, 7standard cabins can be loaded into one 40ft HC.
From the dealer’s workshop to the client’s place, it can be delivered by 6m long truck after assembly. The width and height are within traffic limitation.
Why Choose Us?
Other Advantages of
Foldable High Quality Easy Assembly Sip Panel House Kit
|
1 |
Strong Structure
|
All parts are galvanized, lifetime more than 30 years. Can be stacked up to 3 floors. |
|
2 |
Modular Design
|
They are able to stack each other and fixed through high tensile screws. |
|
3 |
Factory Quick Respond
|
Modular design minimized and standardized part. That makes quick combination and respond possible. |
|
4 |
Minimized Site Work |
The assembly only requests simple tools. That helps to save equipment cost and labor cost. No cast-in-situ concrete slab is needed. The original floor such as turf will not be damaged.
|
