Model
|
U-BOX-M4
|
|
Size
|
Machine size 114.5x114.5x54.1mm
|
|
Material
|
Metal body
|
|
Color
|
Available in Black, Iron Gray
|
|
Processor Support
|
Onboard Intel Core 11th Generation Tiger Lake-U/-H Series Processor
|
|
Memory
|
2*DDR4 SO-DIMM, up to 64GB total
|
|
Storage
|
1*M.2 M-Key 2280 (PCIe3.0 x4 NVMe/SATA3.0 protocol either one)
|
|
Network Card
|
Intel i226-V network card, single and dual network optional (for single network, 1 more USB3.0 at the back)
|
|
Wireless
|
Optional M.2 E-Key WIFI/BT with built-in antenna
|
|
TPM
|
External TPM2.0 optional
|
|
I/O Interface
|
Switch button, reset hole
|
|
|
Intel i226-V network card (single and dual network optional)
|
|
|
2*HDMI2.0 ports, 2 Type-C ports (USB3.2 + DP)
|
|
|
1*DC power hole
|
|
|
1*2-in-1 audio hole
|
|
|
2*USB3.2 port, 2*USB2.0 port
|
|
Power Supplies
|
DC 12-19V, 90W and above
|
|
OS Support
|
Windows 10, Windows 11, Linux, etc.
|
|
Packaging
|
Neutral white box package, 181x152x115mm
|
|
Weight per unit
|
Net weight of computer box 1000g (without adapter)
|
