Quick Details
-
Model Number:
-
SR-VCA
-
Certificate:
-
CE,ISO
-
Warranty:
-
5 years
-
Inner tank material:
-
SUS304-2B stainless steel
-
Outer tank material:
-
SUS304-2B stainless steel
-
Insulation:
-
polyurethane foam
-
Vacuum tube:
-
borosilicate glass 3.3; AL-SS-CU absorb coating
-
Frame material:
-
Aluminum alloy or SUS304-2B stainless steel
-
Seal material:
-
Stabilized high temperature silicon
Quick Details
-
Pipe Material:
-
Glass
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
sunrise
-
Model Number:
-
SR-VCA
-
Certificate:
-
CE,ISO
-
Warranty:
-
5 years
-
Inner tank material:
-
SUS304-2B stainless steel
-
Outer tank material:
-
SUS304-2B stainless steel
-
Insulation:
-
polyurethane foam
-
Vacuum tube:
-
borosilicate glass 3.3; AL-SS-CU absorb coating
-
Frame material:
-
Aluminum alloy or SUS304-2B stainless steel
-
Seal material:
-
Stabilized high temperature silicon
| Model | Diameter tube (mm) | Length tube (mm) | No. (pcs) |
Absorb Area
(m2) |
Quantity
20GP/40GP/40HQ (sets) |
| SR-VCA-24 | 58 | 1800 | 24 | 3.23 | 52/106/129 |
| SR-VCA-30 | 30 | 4.03 | 47/96/118 | ||
| SR-VCA-48 | 48 | 6.46 | 36/74/90 | ||
| SR-VCA-60 | 60 | 8.07 | 31/63/77 |
Technical Specification
1. Inner tank material: SUS304-2B stainless steel
2. Outer tank material: SUS304-2B stainless steel
3. Insulation: polyurethane foam
4. Vacuum tube material: borosilicate glass 3.3; AL-SS-CU absorb coating
5. Frame material: stainless steel
6. Diameter of inlet & outlet: 29mm
