The battery is powered by an upgraded smart BMS circuit, which can resist load and temperature fluctuations.
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
BSLBATT
-
Model Number:
-
B-LFP12-100
-
Battery Size:
-
12V 100AH
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
15KGS
-
Product name:
-
slimline lithium battery lipo4 battery 12v 100ah empty battery
-
Capacity:
-
100AH
-
Voltage:
-
12V
-
Cycle life:
-
more than 3000 Times 100%DOD
-
OEM/ODM:
-
Warmly Welcomed
-
Self Discharge:
-
<1% per Month
-
Output voltage range:
-
10.0 -14.6V
-
Life at 100% DoD (depth of discharge):
-
> more than 4000 cycles
-
Thermal Management:
-
Nature cooling
-
Usage:
-
Marine, RV, Sweeper, Golf cart, Energy storage
-
Certification:
-
CE/MSDS/UN38.3
Quick Details
-
Storage Type:
-
dry
-
Anode Material:
-
LFP
-
Application:
-
Toys, Consumer Electronics
-
Brand Name:
-
BSLBATT
-
Model Number:
-
B-LFP12-100
-
Battery Size:
-
12V 100AH
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
15KGS
-
Product name:
-
slimline lithium battery lipo4 battery 12v 100ah empty battery
-
Capacity:
-
100AH
-
Voltage:
-
12V
-
Cycle life:
-
more than 3000 Times 100%DOD
-
OEM/ODM:
-
Warmly Welcomed
-
Self Discharge:
-
<1% per Month
-
Output voltage range:
-
10.0 -14.6V
-
Life at 100% DoD (depth of discharge):
-
> more than 4000 cycles
-
Thermal Management:
-
Nature cooling
-
Usage:
-
Marine, RV, Sweeper, Golf cart, Energy storage
-
Certification:
-
CE/MSDS/UN38.3
Products Description
|
Items
|
Parameter
|
|
Battery Type
|
100Ah Slim Lithium batteries 12V
|
|
Product Name
|
BSLBATT slimline lithium battery lipo4 battery 12v 100ah empty battery case for lithium
|
|
Nominal Voltage
|
12.8V
|
|
Nominal Capacity
|
100Ah
|
|
Energy
|
1280WH
|
|
Dimensions (L x W x H)
|
(270*600*65)mm
|
|
Weight
|
15kg
|
|
Internal Resistance Fully Charged @25℃
|
≤10mOhms
|
|
Thermal Management
|
Nature cooling
|
|
Mounting orientation:
|
Horizontal or vertical
|
|
Case Material
|
Strong aluminum enclosure
|
|
Certifications
|
CE/ISO/UN38.3/MSDS
|
|
Efficiency
|
99%
|
|
Self Discharge
|
<1% per Month
|
|
Series & Parallel Application
|
max. 6 series or 6 parallel connected application
|
|
Recommended float charge voltage:
|
Less than or equal to 62.5A
|
|
Allowed max charge current:
|
100A
|
|
Output voltage range:
|
10.0 – 14.6V
|
|
Operating Humidity
|
60±25%R.H.
|
|
Max continuous discharge current:
|
100A
|
|
Pulse discharge current:
|
200A (3s)
|
|
Discharge cut-off voltage:
|
10V
|
|
Discharge Temperature
|
-4 to 140 ºF (-20 to 60 ºC)
|
|
Charge Temperature
|
32 to 113 ºF (0 to 45 ºC)
|
|
Storage Temperature
|
23 to 95 ºF (-5 to 35 ºC)
|
|
Life at 100% DoD (depth of discharge):
|
> more than 4000 cycles
|
Products Details
Remarkable BMS
The new BSLBATT series LiFePO4 energy storage battery has a single-cell temperature measurement error of ±1℃ and a voltage measurement error of ≤5mV.
The 12v 100ah slimline lithium battery features an LCD screen on the top of the battery to allow you to easily see your battery
level of charge at any point in time. The screen is backlit to allow for ease of use whether it’s day or night.
level of charge at any point in time. The screen is backlit to allow for ease of use whether it’s day or night.
Use the BSLBATT Bluetooth mode to export data into understandable information, stream it directly to your phone, or use the BSLBATT screen for real-time viewing.
The latest BSLBATT auto-balancing function ensures that all internal battery pouches charge consistently, improving your battery’s charging efficiency and extending its service life.
The 12v 100ah slimline lithium battery is equipped with twin 120A Anderson Style Connectors. Both of these can be used for high current charging and discharging.
Applications Scenarios
Recommend Products
Customer Project
Why Choose Us
---Wisdom Industrial Power Co. Ltd is professional for R&D and manufacturing lithium battery systems
more than 18 years.
In 2003 Wisdom Power develops and produces advanced series “BSLBATT” brand for lithium battery.
---BSLBATT Lithium has an integrated BMS (Battery Management System), which maximizes the performance of the battery by balancing the cells and protecting them from being overcharged or over-discharged.BSLBATT lithium offer at least 5 years warranty as well as provide testing reports to our clients after finishing production.
---Wisdom Power have attained internationa l certifications of ISO9001 and the lithium product has passed CE, CB, UN38.3 and IEC approvals. Our service teams provide 24/7 after sales service and online training for the customers. If you want to get more detail ,please feel free to contact us.
---BSLBATT Lithium has an integrated BMS (Battery Management System), which maximizes the performance of the battery by balancing the cells and protecting them from being overcharged or over-discharged.BSLBATT lithium offer at least 5 years warranty as well as provide testing reports to our clients after finishing production.
---Wisdom Power have attained internationa l certifications of ISO9001 and the lithium product has passed CE, CB, UN38.3 and IEC approvals. Our service teams provide 24/7 after sales service and online training for the customers. If you want to get more detail ,please feel free to contact us.
FAQ
Q1: What is the biggest difference between your battery and other suppliers?
A1: Over 18 Years production experience with this model battery; Battery made of UL UN38.3 MSDS certificated battery cell , PCB structure Battery module, Build in Smart BMS for protection ; All cells we adopt are brand new Grade A !other supplier maybe sell seconds on best quality prices.
Q2: Is this product safe?
A2: Passed the overcharge, over discharge, over temperature, short circuit, acupuncture and other safety tests, no fire, no explosion at any circumstance;
Q3. What's the Lead time of the battery?
A3: 3-10 work days; Specific Lead time depend on the quantity and requirement
Q4: Is it OK to print my logo on the product?
A4. Sure. Please inform us formally before our production and confirm the design first based on our sample.
Q5:How to proceed with an order?
A5. Firstly let us know your requirements or application. Secondly , We quote according to your requirements or our suggestions. Thirdly customer confirm the order details and place a deposit for formal order. Fourthly after receiving payment, we will arrange the production asap and keep you updated during the whole business.
A1: Over 18 Years production experience with this model battery; Battery made of UL UN38.3 MSDS certificated battery cell , PCB structure Battery module, Build in Smart BMS for protection ; All cells we adopt are brand new Grade A !other supplier maybe sell seconds on best quality prices.
Q2: Is this product safe?
A2: Passed the overcharge, over discharge, over temperature, short circuit, acupuncture and other safety tests, no fire, no explosion at any circumstance;
Q3. What's the Lead time of the battery?
A3: 3-10 work days; Specific Lead time depend on the quantity and requirement
Q4: Is it OK to print my logo on the product?
A4. Sure. Please inform us formally before our production and confirm the design first based on our sample.
Q5:How to proceed with an order?
A5. Firstly let us know your requirements or application. Secondly , We quote according to your requirements or our suggestions. Thirdly customer confirm the order details and place a deposit for formal order. Fourthly after receiving payment, we will arrange the production asap and keep you updated during the whole business.
