Quick Details
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
P10
-
Tube Chip Color:
-
Full Color RGB
-
Display Function:
-
Video/graphic/animation/text
-
Suggest viewing distance:
-
10-50m
-
IP Rating:
-
IP65
-
Light Beads:
-
SMD3535
-
Viewing angle:
-
(H/V) 140°/120°
-
LED chip:
-
Epistar
-
Life span:
-
100000hours
-
Warranty:
-
3years
-
Brightness:
-
6500cd/sqm
Quick Details
-
Application:
-
Outdoor
-
Brand Name:
-
LLR
-
Panel Size:
-
320x160mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
P10
-
Tube Chip Color:
-
Full Color RGB
-
Display Function:
-
Video/graphic/animation/text
-
Suggest viewing distance:
-
10-50m
-
IP Rating:
-
IP65
-
Light Beads:
-
SMD3535
-
Viewing angle:
-
(H/V) 140°/120°
-
LED chip:
-
Epistar
-
Life span:
-
100000hours
-
Warranty:
-
3years
-
Brightness:
-
6500cd/sqm
| PROJECT | Outdoor p10 led display |
| Pixel pitch | 10mm |
| Pixel density | 10000 dots |
| Cabinet size(W*H) | 960mmx960mm |
| Cabinet Resolution | 96*96 |
| Scaning mode |
1/4,1/2 |
| Light beads | SMD3535 |
| Brightness (White balance) | 6500cd/sqm |
| View angle | H / V 140°/120° |
| Power consumption(one cabinet) | Max:800W/sqm. Average:300W/sqm. |
| Operating Voltage | AC100V±10% or 220V ±10%; 50---60HZ |
| Net weight | About 39 Kg/M² for Iron Cabinet |
| Working temperature | -20°C----+50°C |
| Operating humidity | 10%-75%RH |
| Life time | ≥100,000hours |
| Refresh rate | 2000Hz /s |
| Control distance | 100m (without repeater), single mode fiber:20km, multi mode fiber: 500m |
| Power | 110V/220V±15% 50--60Hz |
| LED control system | LINSN,Dbstar,Nova-star,ZDEC,Colorlight is selectable |
| Operating system | Windows 2000 / Windows Xp / Windows 7,8,10 |
| Protection level | IP65 |
Outdoor Full Color SMD Led Module P10 Detail
1.Outdoor HD LED Display Leader
Outdoor HD LED Display leader, mature product, functions two years ahead of competitors, worldwide
fantastic projects. Core tech "King Kong" series standard Modules help clients upgrade to better resolution. Increase the chance to have the second sales and enhance the relationships with clients.
2.Protection Rate IP65 and Module Style Design
Protection rate IP65, installation without frame. Module Style Design, fast installation and easy maintenance with low cost.
3 . No Distortion, Power and Control System Back-up Technology Deep black surface, firm & flat, anti-UV mask, make sure the flatness and no distortion. Power and control system back-up technology solution available.
