Quick Details
-
Cooling Mode:
-
WATER COOLING
-
Control Software:
-
EZCAD
-
Place of Origin:
-
China
-
Brand Name:
-
Vank
-
Weight (KG):
-
52 KG
-
Product name:
-
UV Lazer Marking Machine
-
Laser Power:
-
3W/5W
-
Laser source:
-
Raycus Max JPT
-
Applicable Material:
-
Metal Plastic
-
Keywords:
-
UV Laser Marking Machine
Quick Details
-
Working Accuracy:
-
0.001mm
-
Graphic Format Supported:
-
AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT
-
Laser Type:
-
UV
-
Cooling Mode:
-
WATER COOLING
-
Control Software:
-
EZCAD
-
Place of Origin:
-
China
-
Brand Name:
-
Vank
-
Weight (KG):
-
52 KG
-
Product name:
-
UV Lazer Marking Machine
-
Laser Power:
-
3W/5W
-
Laser source:
-
Raycus Max JPT
-
Applicable Material:
-
Metal Plastic
-
Keywords:
-
UV Laser Marking Machine
VankLaser - DUBAI FESPA Middle East 2024！
Application Advantages:
1. Suitable for various material and catagory like 3C, LED Lineation, Silcon Processing.
2. High Quality Beam, focusing spot is smaller, that can achieve hyper fine marking
3. Thermal impact area is very small, will not produce thermal effect, will not produce material burning problem
4. Stable performance, small size , low power consumption.
5. The machine can be compatible with software files such as Coredraw, AutoCAD, Photoshop;PLT,PCX,DXF,BMP,etc supported.
6. Applicable Material: Cosmetics, Drugs, Food and other Macro-molecule material packaging surface, Flexible PCB, LCD Glass QR Code, Metal Surface Coating, Plastic Keys, Electronic Componentsm Gifts, Communication Equipment, Construction Materials,etc
2. High Quality Beam, focusing spot is smaller, that can achieve hyper fine marking
3. Thermal impact area is very small, will not produce thermal effect, will not produce material burning problem
4. Stable performance, small size , low power consumption.
5. The machine can be compatible with software files such as Coredraw, AutoCAD, Photoshop;PLT,PCX,DXF,BMP,etc supported.
6. Applicable Material: Cosmetics, Drugs, Food and other Macro-molecule material packaging surface, Flexible PCB, LCD Glass QR Code, Metal Surface Coating, Plastic Keys, Electronic Componentsm Gifts, Communication Equipment, Construction Materials,etc
Product Description
Specification
|
Model
|
Uv Laser Marking Machine
|
|
Laser Source
|
Gainlaser
|
|
Galvanometer
|
UV Galvo Scanner Head
|
|
Control Card
|
EZCAD2
|
|
PowerSupplies
|
5V,15V,24V
|
|
Z-Axis Control
|
Manual
|
|
CoolingSystem
|
Water Cooling
|
|
Optional Lens
|
70*70 / 110*110/ 200*200 / 300*300
|
|
Power Requirements
|
AC220V/50HzOr AC110V / 60Hz(According to local electricity supply)
|
|
Rotary
|
Optional
|
|
Pulse width
|
10-50ns
|
|
Warranty
|
1 Year
|
|
Temperature/Humidity
|
15~30℃ / 20~80%
|
|
Laser Power
|
3W/5W
|
|
Laser Wavelength
|
355nm
|
|
Beam Quality
|
M²＜1.2
|
|
Laser Repetition frequency
|
30-150kHz
|
|
Pluse Duration
|
<15ns
|
|
Marking Line Speed
|
≤5000mm/s
|
|
Power Consumption
|
≤1500w
|
|
Engraving Depth
|
≤0.5mm(lt depends on the material)
|
|
Repeating Precision
|
+0.003mm
|
|
Beam Diameter
|
~0.45mm
|
|
Fiber Power
|
Adjustablefrom 1% - 100%
|
|
Operation System
|
Win7 / Win8 / Win10 / Win11
|
|
Marking Format
|
AI、DXF、PLT、JPG、BMP、Bar Code、QR Code、etc.
|
