Quick Details
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
IPC-HDBW71242H-Z
-
Video Compression Format:
-
265
-
Resolution:
-
12MP
-
Type:
-
poe camera
-
Color:
-
white color
-
lens:
-
2.7 mm~12 mm
-
Material:
-
Full metal
-
Motion Detection:
-
4 areas
-
power:
-
poe
-
Night vision:
-
40m IR distance
-
APP:
-
DH Partner
Quick Details
-
Special Features:
-
NIGHT VISION, Motion Detection, People Counting, Face Recognition
-
Function:
-
PAN-TILT, NIGHT VISION, Waterproof / Weatherproof, Vandal-proof
-
Customized support:
-
Online technical support, Customized logo, Software reengineering, OEM, ODM
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
IPC-HDBW71242H-Z
-
Video Compression Format:
-
265
-
Resolution:
-
12MP
-
Type:
-
poe camera
-
Color:
-
white color
-
lens:
-
2.7 mm~12 mm
-
Material:
-
Full metal
-
Motion Detection:
-
4 areas
-
power:
-
poe
-
Night vision:
-
40m IR distance
-
APP:
-
DH Partner
Product Description
8MP 4K Lite IR Vari-focal Vandalproof Dome Network Camera Security IP Camera IPC-HDBW2831R-ZAS-S2
IPC-HDBW71242H-Z
12MP IR Dome WizMind Network Camera
> 12MP 1/1.7” CMOS image sensor, high image definition
> Outputs max. 12MP (4000 × 3000) @25/30 fps
> H.265 codec, high compression rate, ultra-low bit rate
> Built-in IR LED, max. IR distance: 40 m
> Rotation mode, DWDR, 3D NR, HLC, BLC, digital watermarking
> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
> Perimeter Protection , Face Detection , Video Metadata , ANPR , People Counting , Queue Management
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card
> 24V AC/12V DC/PoE power supply; 12V DC power output, max. current 165mA; easy for installation.
> IP67, IK10 protection
> Anti-corrosion coating (optional)
> Five streams for three-channel HD video
12MP IR Dome WizMind Network Camera
> 12MP 1/1.7” CMOS image sensor, high image definition
> Outputs max. 12MP (4000 × 3000) @25/30 fps
> H.265 codec, high compression rate, ultra-low bit rate
> Built-in IR LED, max. IR distance: 40 m
> Rotation mode, DWDR, 3D NR, HLC, BLC, digital watermarking
> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
> Perimeter Protection , Face Detection , Video Metadata , ANPR , People Counting , Queue Management
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card
> 24V AC/12V DC/PoE power supply; 12V DC power output, max. current 165mA; easy for installation.
> IP67, IK10 protection
> Anti-corrosion coating (optional)
> Five streams for three-channel HD video
|
Camera
|
|
|
Image Sensor
|
1/1.7”12Megapixel progressive CMOS
|
|
Max. Resolution
|
4000 (H) × 3000 (V)
|
|
ROM
|
4 GB
|
|
RAM
|
2 GB
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
Auto/Manual 1/3 s–1/100,000 s
|
|
Min. Illumination
|
0.01 Lux@F1.8 (Color, 30IRE)
0.001 Lux@F1.8 (B/W, 30IRE) 0 Lux (Illuminator on) |
|
S/N Ratio
|
>56 dB
|
|
Illumination Distance
|
40 m (131.2 ft) (IR LED)
|
|
Illuminator On/Off Control
|
Auto/Manual
|
|
Illuminator Number
|
3 (IR LEDs)
|
|
Pan/Tilt/Rotation Range
|
Pan: 0°–355°
|
|
|
Tilt: 0°–80°
|
|
|
Rotation: 0°–355°
|
|
Lens
|
|
|
Lens Type
|
Motorized vari-focal
|
|
Mount Type
|
φ14
|
|
Focal Length
|
2.7 mm–12 mm
|
|
Max. Aperture
|
F1.8
|
|
Field of View
|
Pan: 103°–44°
|
|
|
Tilt: 75°–33°
|
|
|
Diagonal: 135°–55°
|
|
Iris Type
|
Auto
|
|
Close Focus Distance
|
1.2 m (3.9 ft)
|
|
DORI Distance
|
|
|
Lens (W)
|
D: 97m, O: 38 m, R: 19 m, I: 9 m
|
|
Lens (T)
|
D: 205 m, O: 82 m, R: 41 m, I: 20 m
|
|
Smart Event
|
|
|
IVS
|
Abandoned object; missing object
|
|
Professional, intelligent
|
IVS (Perimeter Protection); Face Detection; Face Recognition; Face and Body Detection; People Counting; ANPR; Video Metadata; Intelligent Search
|
|
Video
|
|
|
Video Compression
|
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
|
|
Smart Codec
|
Smart H.264+
Smart H.265+ |
|
Video Frame Rate
|
Main stream: 4000 × 3000 @1-25/30 fps
Sub stream: 704 × 576 @1-25 fps; 704 × 480 @1-30 fps
Third stream: 1920 × 1080 @1-25/30 fps
Fourth stream: 1920 × 1080 @1-25/30 fps
Fifth stream: 704 × 576 @1-25 fps; 704 × 480 @1-30 fps
|
|
Stream Capability
|
5 streams
|
|
Resolution
|
12M (4000 × 3000); 8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728); 5M (2592 × 1944); 4M (2688 × 1520); 3M (2048 × 1536); 3M (2304 × 1296); 2M (1920 × 1080); 1.3M (1280 × 960); 720P (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240); VGA
(640 × 480) |
|
Bit Rate Control
|
CBR/VBR
|
|
Video Bit Rate
|
H.264: 32 kbps–16384 kbps H.265: 32 kbps–14080 kbps
|
|
Day/Night
|
Auto(ICR)/Color/B/W
|
|
BLC
|
Yes
|
|
HLC
|
Yes
|
|
DWDR
|
Yes
|
|
White Balance
|
Auto/natural/street lamp/outdoor/manual/regional custom
|
|
Gain Control
|
Auto/Manual
|
|
Noise Reduction
|
3D NR
|
|
Motion Detection
|
OFF/ON (4 areas, rectangular)
|
|
Region of Interest(RoI)
|
Yes (4 areas)
|
|
Smart Illumination
|
Yes
|
|
Image Rotation
|
0°/90°/180°/270° (Supports 90°/270° with 3840 × 2160 resolution and lower.)
|
|
Mirror
|
Yes
|
|
Privacy Masking
|
4 areas
|
|
Audio
|
|
|
Audio Compression
|
G.711a; G.711Mu; G.726
|
|
Alarm
|
|
|
Alarm Event
|
No SD card; SD card full; SD card error; network disconnection; IP conflict; motion detection; video tampering; tripwire;
intrusion; illegal access; voltage detection; audio detection; safety exception; local alarm |
|
Network
|
|
|
Network
|
RJ-45 (10/100 Base-T)
|
|
SDK and API
|
Yes
|
|
Cyber Security
|
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering;
generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
|
Protocol
|
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP;
NFS; PPPoE; Bonjour |
|
Interoperability
|
ON-VIF(Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec
|
|
User/Host
|
20 (Total bandwidth: 240 M)
|
|
Storage
|
FTP; SFTP; Micro SD Card (support max. 256 GB); NAS
|
|
Browser
|
IE
|
|
|
Chrome
|
|
|
Firefox
|
|
Management Software
|
Smart PSS; DSS; DMSS
|
|
Mobile Phone
|
IOS; Android
|
|
Certification
|
|
|
Certifications
|
CE-LVD: EN62368-1
|
|
|
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
|
|
|
FCC: 47 CFR FCC Part 15, Subpart B
|
|
|
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
|
|
Port
|
|
|
RS-485
|
1 (baud rate range: 1200 bps–115200 bps)
|
|
Audio Input
|
1 channel (3-pin terminal with 2.54mm clearance; with audio cable)
|
|
Audio Output
|
1 channel (3-pin terminal with 2.54mm clearance; with audio cable)
|
|
Alarm Input
|
3 channels in: 5mA 3V–5V DC
|
|
Alarm Output
|
2 channels out: 1,000mA 30V DC/500mA 50V DC
|
|
Power
|
|
|
Power Supply
|
12V DC/24V AC/POE+(802.3at); ePoE
|
|
Power Consumption
|
Basic power consumption: 6.1W (12V DC); 6.1W (24V AC active power); 5.4W (PoE)
Max. power consumption: 17.9W (12V DC); 17.1W(24V AC active power); 16.8W (PoE) |
|
Environment
|
|
|
Operating Conditions
|
–40°C to +60°C (–40°F to +140°F) /Less than 95% RH
|
|
Storage Temperature
|
–40°C to +60°C (–40°F to +140°F)
|
|
Protection
|
IP67, IK10
|
|
Structure
|
|
|
Casing
|
Metal + plastic
|
|
Dimensions
|
129.1 mm × Φ157.9 mm (5.08" × Φ6.22")
|
|
Net Weight
|
1.5 kg (3.31 lb)
|
|
Gross Weight
|
1.6 kg (3.53 lb)
|
|
