Quick Details
-
Brand Name:
-
Juniper
-
Model Number:
-
QFX5120-32C-AFO
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
Juniper Networks QFX5120-32C-AFO Switch
-
Network Ports:
-
32x 100 Gigabit Ethernet QSFP28
-
Management Ports:
-
1x USB, 1x Console RJ45
-
Processor:
-
A 2.2 GHz quad-core Intel CPU with 16 GB memory and 64 GB SSD storage
-
irmware Version:
-
Advanced Junos OS
-
Switching Capacity:
-
3.2 Tbps
-
Power Supplies Included:
-
2x JPSU-850W-AC-AFO AC PSU's Included - Front to Back Airflow
-
Forwarding Rate:
-
2 Bpps
-
MAC Address Table Size:
-
288,000
-
Latency:
-
as low as 550 nanoseconds
Quick Details
-
Transmission Rate:
-
10/100/1000Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
Other
-
Brand Name:
-
Juniper
-
Model Number:
-
QFX5120-32C-AFO
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
Juniper Networks QFX5120-32C-AFO Switch
-
Network Ports:
-
32x 100 Gigabit Ethernet QSFP28
-
Management Ports:
-
1x USB, 1x Console RJ45
-
Processor:
-
A 2.2 GHz quad-core Intel CPU with 16 GB memory and 64 GB SSD storage
-
irmware Version:
-
Advanced Junos OS
-
Switching Capacity:
-
3.2 Tbps
-
Power Supplies Included:
-
2x JPSU-850W-AC-AFO AC PSU's Included - Front to Back Airflow
-
Forwarding Rate:
-
2 Bpps
-
MAC Address Table Size:
-
288,000
-
Latency:
-
as low as 550 nanoseconds
Juniper Networks QFX5120-32C-AFO QFX5120 Series 32x 100GB QSFP28 F-B Airflow Ethernet Switch
The QFX5210 Switch is a flexible, 64-port, fixed-configuration switch designed for spine-and-leaf applications in next-generation IP fabric networks. Featuring line-rate, high-density QSFP+/QSFP28 ports supporting 10GbE, 25GbE, 40GbE, and 100GbE connections, the QFX5210 offers an advanced Layer 2, Layer 3, and MPLS feature set. This allows network operators to build large, high-density IP fabrics that support network virtualization and intelligent traffic forwarding based on proven, Internet-scale technology, while enabling easy upgrades to 25GbE servers.
Additionally, the QFX5210-64C-S platform includes support for SONiC, continuing Juniper’s commitment to disaggregation, allowing customers to innovate quickly and easily while simplifying operations.
Product Description
| Model: | QFX5120-48Y | QFX5120-48YM | QFX5120-48T | QFX5120-32C |
|---|---|---|---|---|
|
Dimensions
(H x W x D) |
4 Tbps (bidirectional)/1.31 Bpps
Cut-through and store-andforward |
4 Tbps (bidirectional)/1.31 Bpps
Cut-through and store-andforward |
2.16 Tbps (bidirectional)/1001.7 Mpps
Cut-through and store-andforward |
6.4 Tbps (bidirectional)/2 Bpps
Cut-through and store-andforward |
| Weight | 23.7 lb (10.75 kg) | 24.8 lb (11.25 kg) | 24.25 lb (11 kg) | 21.12 lb (9.58 kg) |
| Switching Capacity |
1.72 x 17.36 x 20.48 in.
(4.37 x 44.09 x 52.02 cm) |
1.72 x 17.36 x 20.48 in.
(4.37 x 44.09 x 52.02 cm) |
1.72 x 17.36 x 20.48 in.
(4.37 x 44.09 x 52.02 cm) |
1.7 x 17.26 x 20.27 in.
(4.32 x 43.84 x 51.5 cm) |
| Power Consumption |
Max load: 450 W
Typical load: 260 W |
Max load: 650 W
Typical load: 550 W |
Max load: 450 W
Typical load: 300 W |
Max load: 515 W
Typical load: 380 W |
| Interface Options |
|
|
|
|
