Quick Details
-
Surface treatment:
-
Anodizing
-
Color:
-
customized
-
Material:
-
Alloy 6063/6061/6005/6060 T5/T6
-
Length:
-
According to your requirement
-
Certification:
-
ISO9001:2008
-
MOQ:
-
1kg
-
Size:
-
Drawings
-
Payment term:
-
T/T
Quick Details
-
Grade:
-
6000 Series
-
Place of Origin:
-
Henan, China
-
Product name:
-
Perfil de aluminio para correderas armarios vidro Producer profile
-
Surface treatment:
-
Anodizing
-
Color:
-
customized
-
Material:
-
Alloy 6063/6061/6005/6060 T5/T6
-
Length:
-
According to your requirement
-
Certification:
-
ISO9001:2008
-
MOQ:
-
1kg
-
Size:
-
Drawings
-
Payment term:
-
T/T
Perfil de aluminio para ventanas y puertas corredizas corredera telhado de armario vidro Supplier Producer profile
PRODUCT INFORMATION
Product ingredient list
| NO. | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Other | Total | Al |
| 6005 |
0.6- 0.9 |
0.35 | 0.1 | 0.1 |
0.4- 0.6 |
0.1 | 0 | 0.1 | 0.1 | 0.05 | 0.15 | rest |
| 6061 |
0.4- 0.8 |
0.7 | 0.15-0.4 | 0.15 |
0.8- 1.2 |
0.04- 0.35 |
0 | 0.25 | 0.15 | 0.05 | 0.15 | rest |
| 6063 |
0.2- 0.6 |
0.35 | 0.1 | 0.1 | 0.45-0.9 | 0.1 | 0 | 0.1 | 0.1 | 0.05 | 0.15 | rest |
| Place of Origin | Henan,China |
| Grade | 6000 Series |
| Temper | T3-T8 |
| Application | Decorations, Robot Frame, workstations, etc |
| Shape | T - Profile |
| Alloy Or Not | Is Alloy |
| Model Number | HY-YXC024 |
| Brand Name | Huayang |
| Product name | Perfil de aluminio para puertas correderas armarios vidro Supplier Producer profile |
| Surface treatment | Anodizing |
| Color | Customized |
| Material | Alloy 6063/6061/6005/6060 T5/T6 |
| Length | According to your requirement |
| Certification | ISO9001:2008 |
| MOQ | 1Kg |
| Size | Drawings |
| Payment term | T/T |
54444
on
| NO. | Size |
Material |
KG/M | Shape |
| LSX-001 | 40*40 | 6063-T5 | 1.259 | T-shape |
| HY-LSX003 | 46*32 | 6063-T6 | 1.539 | T-shape |
| LSX-002 | 40*80 | 6063-T5 | 2.137 | V-shape |
| HY-30X30LSX | 30*30 | 6063-T5 | 0.834 | T-shape |
| HY-026 | 20*20 | 1060 | 0.457 | T-shape |
| HY-LSX4020 | 40*20 | 6063-T5 | 0.774 | V-shape |
| HY-LSX2020 | 20*20 | 6063-T5 | 0.629 | V-shape |
From the imagination to the finished product, we need to go through many processes, and of course
we can't lack us.
First, engineers need to design the drawings of the desired products
(if you don't have drawings,
we can help you draw the drawings)
Second, the factory personnel send the drawings to the mold factory, and the mold factory opens the
mold according to the drawings.
Third, buying raw materials for finished products is the most basic
and most important.
Fourth, the extrusion is performed according to the mold.
Fifth, cut the
extruded p
roduct.
Sixth, surface treatment is performed.
Seventh, oxidation treatment, cooling.
Eighth, the product is packaged.
Ninth, arrange transportation.
ABOUT US
Gongyi huayang aluminum aluminum profile co., LTD
is a research and development and production,
sales as one integrated aluminum, large-scale private enterprises, is a modern production technology,
specializing in the production of civil aluminum, industrial aluminum and different profile, mainly produces
aluminum cage materials, aluminum pipe, aluminum pipe, pipeline, radiator, etc. The company introduces
the international and domestic advanced aluminum processing equipment, a full set of automatic production
line, has the abundant technical force, sophisticated production technology, perfect detection means,
increasing productivity can be produce according to customer's requirements, to meet the different needs
of customers. Of customers trust and support is our biggest motivation, we will constantly strive to technology
innovation, the pursuit of excellent quality, sincere return customers, support customer.
Each product has a suitable packaging method. The right packaging can not only ensure the quality of the product
but also enhance the aesthetics. After selecting our products, the packaging method can be customized according
to our experience or by you. Looking forward to your customization!
4
| Quick Q&A that might save some of your concerns. | |
| Q1.Are you a factory or trading company? | A:We're a self-own factory,with export license. |
| Q2.What is your lead time for new molds&mass production? |
A:*7-10 days to build the new moulds. *Mass production takes 20-25days for a 20gp,25-30days for a 40hq. |
| Q3.What is your minimum order quantity? | 1KG/1M/1PC |
| Q4.What certification do you have? | A:We are certificated by ISO9001:2008,Factory is reliable and quanlity is guaranteed.Before mass production,we will test the mould till its quality pass.In the production,you order will be followed by QC during every step.Every production must be checked and signed before they move to the next process. |
| Q5.What is your terms of payment? |
A:*Payment <=10000USD,100% in advance. *Payment>10000USD,30% T/T in advance,balance before shipment. |
| Q6.Can you send me samples? | A:Yes,Free samples,with freight is on your side. |
| Q7.What is your package? | A:Craft paper/Carton bos/Plastic film. |
| Q8.Location?How can I visit there? |
A:*Our factory located in Gongyi,Henan,China. *The nearest airport is Xinzheng airport.The nearest G-series high-speed train is GongYiNan Railway Station. |
