Quick Details
-
Warranty(Year):
-
4-Year
-
Lamp Luminous Flux(lm):
-
1080
-
Model Number:
-
gr505604
-
Place of Origin:
-
Guangdong, China
-
Keyword:
-
Ceiling Spot Downlight
-
Material:
-
Aluminum Housing
-
Installation:
-
Surface Mounted Mode
-
Power:
-
5W/7W/12W/15W/18W/20W/25W/30W
-
Shape:
-
Square Shape
-
Applied range:
-
Dinning Room
-
Dimmable:
-
TRIAC/ELV 10%-100%
-
Voltage:
-
100-277VAC/220V/120V
-
Wattage:
-
3W 4W 6W
Quick Details
-
Lamp Luminous Efficiency(lm/w):
-
90
-
Lamp Body Material:
-
Aluminum
-
Install Style:
-
Downlights
-
Warranty(Year):
-
4-Year
-
Lamp Luminous Flux(lm):
-
1080
-
Model Number:
-
gr505604
-
Place of Origin:
-
Guangdong, China
-
Keyword:
-
Ceiling Spot Downlight
-
Material:
-
Aluminum Housing
-
Installation:
-
Surface Mounted Mode
-
Power:
-
5W/7W/12W/15W/18W/20W/25W/30W
-
Shape:
-
Square Shape
-
Applied range:
-
Dinning Room
-
Dimmable:
-
TRIAC/ELV 10%-100%
-
Voltage:
-
100-277VAC/220V/120V
-
Wattage:
-
3W 4W 6W
| LED power | 3w | 5w | 7w | 10w | 15w | 20w | 30w |
| Output | 300lm | 500lm | 700lm | 1000lm | 1500lm | 2000lm | 3000lm |
| LED Light Source | COB / SMD | ||||||
| Beam angle | 60 degree | ||||||
| Input voltage | AC100-277V | ||||||
| Frequency Range | 50-60HZ | ||||||
| CRI | >80 | ||||||
| Working Temperature | -40°c-65°c | ||||||
| Storage Temperature | -25°c-65°c | ||||||
| Color of housing | Aluminum,white | ||||||
| Lifespan | 50,000+hrs | ||||||
| Certificate | CE/ROHS/ERP/SAA/SASO/GS | ||||||
| COB Parameter | |||||||
| PCB | Ceramic | ||||||
| Chip size | 11MM | 20MM | 20MM | 32MM | 32MM | 42MM | 60MM |
| Output | 300lm | 500lm | 700lm | 1000LM | 1500LM | 2000lm | 3000LM |
| CRI | >80 | ||||||
| Voltage | 30-33vDC | ||||||
| Current | 300mA | ||||||
| Brand options | Cree/ brigelux / wafer | ||||||
| Driver Parameter | |||||||
| Brand | Lifud/Meanwell/EAGLERIES/PHILIPS/TRIDONIC | ||||||
| Input | AC100-277vAC | ||||||
| Output | 30-35vDC,300mA | ||||||
| Power Factor | 0.9-0.99 | ||||||
| Power Efficiency | 88% | ||||||
| Certificate | EMC/TUV/CE/CQC/PSE | ||||||
