Quick Details
-
Brand Name:
-
China
-
Use:
-
FTTH, FTTH
-
Warranty Time:
-
1year, 1 Year
-
Certification:
-
FCC,CE ,RoHS
-
Ethernet Port:
-
8*10/100/1000Base--TX RJ45 port
-
Fiber port:
-
1*1000M optic fiber port
-
Rate:
-
self-adaptive 10/100/1000M
-
Wavelength:
-
1310/1550nm
-
Optic interface:
-
SC/FC/ST
-
Power supply:
-
DC 5V 1A
-
Operating Temperature/Humidity:
-
0~65℃ Operating; -20~65℃ Storage
Quick Details
-
Type:
-
Fiber optic media converter
-
Model Number:
-
ND-920-1FX8TX-SC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
China
-
Use:
-
FTTH, FTTH
-
Warranty Time:
-
1year, 1 Year
-
Certification:
-
FCC,CE ,RoHS
-
Ethernet Port:
-
8*10/100/1000Base--TX RJ45 port
-
Fiber port:
-
1*1000M optic fiber port
-
Rate:
-
self-adaptive 10/100/1000M
-
Wavelength:
-
1310/1550nm
-
Optic interface:
-
SC/FC/ST
-
Power supply:
-
DC 5V 1A
-
Operating Temperature/Humidity:
-
0~65℃ Operating; -20~65℃ Storage
Product Description
Specification
|
Model Number
|
ND-920-1FX8TX-SC
|
|
Material
|
Metal
|
|
Function
|
1、1*1000M SC fiber interface (FC/LC optical port can be customized); 8*10/100M Ethernet interfaces
2、Maximum transmission distance: 0.5 ~ 120 km.
3、The dynamic buffer allocation in front equalizes the network load and prevents blocking. 4、Adopt IEEE802.3 10BaseT Ethernet and IEEE802.3u 100base-tx,IEEE802.3ab 1000base-tx and 1000base-fx fast Ethernet standards;
5、Each UTP exchange port of the exchange port can automatically recognize the straight line (MDI) and the cross line (mdi-x).
6、Support 1024 MAC addresses;
7、Automatic MAC address learning and update function.
8、Select store-and-forward
9、Ballast provides maximum 8G data storage bandwidth; Enable LED indicator light to monitor the working status of each port
|
|
Usage
|
Security, monitoring, communication
|
