Access Control
In the Parking Lot
- Product Details
- {{item.text}}
Quick Details
-
Product:
-
New design automatic retractable gates for parking lot
-
Overall dimension:
-
L*W*H=344*290*1090(mm)
-
Voltage:
-
AC220V±10% 50Hz
-
Motor power:
-
250W
-
Surface treatment:
-
Spraying plastic
-
Noise:
-
≤60dB
-
Motor speed:
-
30r/min
-
Working temperature:
-
-10°C~+45°C(standard) -25°C~+40°C(low temperature)
-
Relative humidity:
-
≤90%, non-condensing
-
Lifetime:
-
≥500 million times
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SEWO
-
Model Number:
-
SEWO-X6
-
Product:
-
New design automatic retractable gates for parking lot
-
Overall dimension:
-
L*W*H=344*290*1090(mm)
-
Voltage:
-
AC220V±10% 50Hz
-
Motor power:
-
250W
-
Surface treatment:
-
Spraying plastic
-
Noise:
-
≤60dB
-
Motor speed:
-
30r/min
-
Working temperature:
-
-10°C~+45°C(standard) -25°C~+40°C(low temperature)
-
Relative humidity:
-
≤90%, non-condensing
-
Lifetime:
-
≥500 million times
Product Description
|
Product Name
|
SEWO Automatic Boom Barrier Folding Arm Security Parking Entrance Gate for Underground Car Garage Parking Traffic Controller
|
|
Model No.
|
T9 series ( SEWO-DZ260 ; SEWO-DZ260C ; SEWO-DZ260E)
|
Features
1 Low noise, more convenient and stable, beam rising time 3-6s.
2 Transmission mechanism use sine link mechanism, and removed the ordinary electric buffer stops for the use of slow device, so
that the whole structure is more compact, reasonable greatly reducing the machinery fault.
3 Main controller can supply many types of running modes for user to meet different requirements.
4 Motor is the low speed and no maintenance, and can be putted in any position without damage. At the two terminal limit position,
the motor power automatic drops to 20W, which can save energy consumption and also can
avoid condensation and corrosion, even in the cold winter can also be normal operation.
5 Special motor loop structure can avoid the instant current and voltage fluctuation when the power cut down suddenly.
6 Impact-proof structure: when accident happens, the vehicle hit against the barrier beam, impact-proof structure make the
baluster rotate for 90°C, which can avoid or reduce the damage from vehicles and barrier.
7 The case was made of steel plate after special treatment, the surface was spraying with advanced salmon pink and saffron
automobile coating, which is rust-proof, and can avoid color fading caused by ultraviolet irradiation.
8 Barrier beam: Aluminum alloy octagon bar, with reinforcement, reliable quality.
9 Installed pressure wave switch, flexible reaction, automatic barrier can prevent smashing car safely and effectively, with
assorting vehicle detector to achieve double prevention.
10 Unique cold light shining prompt beam is the initiative patent in domestic. The light box is adopted the leading cold light
technology, fiber material, long lifetime, supper low power.
2 Transmission mechanism use sine link mechanism, and removed the ordinary electric buffer stops for the use of slow device, so
that the whole structure is more compact, reasonable greatly reducing the machinery fault.
3 Main controller can supply many types of running modes for user to meet different requirements.
4 Motor is the low speed and no maintenance, and can be putted in any position without damage. At the two terminal limit position,
the motor power automatic drops to 20W, which can save energy consumption and also can
avoid condensation and corrosion, even in the cold winter can also be normal operation.
5 Special motor loop structure can avoid the instant current and voltage fluctuation when the power cut down suddenly.
6 Impact-proof structure: when accident happens, the vehicle hit against the barrier beam, impact-proof structure make the
baluster rotate for 90°C, which can avoid or reduce the damage from vehicles and barrier.
7 The case was made of steel plate after special treatment, the surface was spraying with advanced salmon pink and saffron
automobile coating, which is rust-proof, and can avoid color fading caused by ultraviolet irradiation.
8 Barrier beam: Aluminum alloy octagon bar, with reinforcement, reliable quality.
9 Installed pressure wave switch, flexible reaction, automatic barrier can prevent smashing car safely and effectively, with
assorting vehicle detector to achieve double prevention.
10 Unique cold light shining prompt beam is the initiative patent in domestic. The light box is adopted the leading cold light
technology, fiber material, long lifetime, supper low power.
Functions
1) Manual release
2) Machine core with compression spring, effectively avoids the accidents caused by spring breaking
3) Die-casting aluminum alloy motor, precision and good at thermal radiating
4) Motor cooling fan, solving the problem of heat-protection
5) Double safety limit switches (photo electricity limit switch/motor memory sensor)
6) Reversing on obstacle
7) Auto-closing
8) Support the INFRARER PHTOCELL for anti-bumping function (optional)
9) Support the external and internal VEHICLE LOOP DETECTOR (optional)
10) Traffic light interface
11) Wire control (switch signal)/ Remote control (418MHZ)
12) RS485 communication modul
Details Images
SEWO-DZ260
Straight Boom Barrier
SEWO-DZ260C
Folding Boom Barrier
SEWO-DZ260E
Fence Boom Barrier
|
Model No
|
SEWO-DZ260
|
SEWO-DZ260E
|
SEWO-DZ260C
|
||
|
Dimension
|
360L*300W*1050H(mm)
|
|
|
||
|
Net Weight
|
65kg
|
70KG
|
80KG
|
||
|
Working voltage
|
AC220V±10% 50Hz
|
|
|
||
|
Working temperature
|
--40°C~+75°C
|
|
|
||
|
Relative humidity
|
≤95% coagulation free
|
|
|
||
|
Arm direction (optional)
|
leftward/rightward
|
|
|
||
|
Max beam length
|
≤6m
|
≤4.5m
|
≤4.5m
|
||
|
Noise
|
≤60dB
|
|
|
||
|
Motor power
|
100W
|
|
|
||
|
Motor speed
|
30r/min
|
|
|
||
|
Operating principle
|
Worm gear
|
|
|
||
|
Beam
|
Straight beam
|
90°foldable beam
|
2 fence beam
|
||
|
Beam lifting time
|
3~6s
|
6s
|
6s
|
||
|
MCBF
|
≥5,000,000 times
|
|
|
||
|
Working environments
|
indoor, outdoor
|
|
|
||
