Quick Details
-
Max power(Kw/Rmp):
-
19KW(25.84HP)/6500rmp
-
Max Torque(N.m/Rmp):
-
26N.m/6500rmp
-
Max Speed:
-
45KM/H(adjustable)
-
Drivetrain:
-
Shaft-driven
-
Range:
-
300km (loaded 100KG on flat road)
-
Fuel Tank:
-
12L
-
Frame:
-
Welded steel with coated twice
-
Windscreen:
-
Foldable organic glass
-
Climbing capability:
-
40 degrees (fully loaded)
Quick Details
-
Tire Size:
-
18/8.5-8
-
Dimension:
-
3550*1200*1710mm
-
Engine Type:
-
300CC Single cylinder, vertical,4- stroke, water cool, sohc-4 walve
-
Max power(Kw/Rmp):
-
19KW(25.84HP)/6500rmp
-
Max Torque(N.m/Rmp):
-
26N.m/6500rmp
-
Max Speed:
-
45KM/H(adjustable)
-
Drivetrain:
-
Shaft-driven
-
Range:
-
300km (loaded 100KG on flat road)
-
Fuel Tank:
-
12L
-
Frame:
-
Welded steel with coated twice
-
Windscreen:
-
Foldable organic glass
-
Climbing capability:
-
40 degrees (fully loaded)
About us
Yongkang Jinghang Sightseeing Vehicle Co., Ltd has been producing high-quality vehicles since 2002, including golf carts,
sightseeing vehicles, and more. Our factory spans 10,000 square meters and our team of skilled workers ensures quality control
throughout the entire production process. We specialize in gas-powered golf carts and offer OEM services to meet specific client
needs. We have collaborated with leading companies such as EZ and CL and are committed to providing satisfying solutions.
Product Description
19kw durable engine
Golf cart with electronic fuel injection (EFI) and a compression ratio of ten to one. Our golf cart features a pressure splash lubrication system, which ensures smooth operation and long-lasting performance.
CVT Gear
With a maximum power output of 19KW at 6500 rpm and a maximum torque of 26N.m at 6500 rpm, this cart is capable of reaching speeds
of up to 45 km/h. The CVT gear shifter offers effortless shifting between forward, neutral, and reverse modes.
Foldable windshiled
The frame is welded steel with a double-coated finish for added durability. The plastic parts are injection-molded and finished with automotive paint. Moreover, the foldable organic glass windscreen makes driving more comfortable, even in windy conditions.
Hub cover
Our golf cart is designed for exceptional handling, with a wheel track of 840mm/985mm, a wheelbase of 1640mm, and a minimum turning radius of 2900mm. The tires are 24 inch off road tyre with 12inch alloy rim, tubeless. The cart has a ground clearance of 270mm, making it suitable for off-road adventures.
USB charging port
The golf cart is equipped with various electronic systems, including turning signals, head lights, rear lights, brake lights, horn, battery level indicator, forward & reverse switch, and electric locker. The combination switch allows for easy control of the turning lights, head lights, and horn.
Dash board
For added safety, the golf cart features rear hydraulic oil pressure brakes and a pedal-activated parking brake, with a braking
distance of less than 4m. The front independent suspension and rear leaf spring suspension ensure a smooth ride, even on rough
terrain.
distance of less than 4m. The front independent suspension and rear leaf spring suspension ensure a smooth ride, even on rough
terrain.
Specification
|
item
|
value
|
|
Minimum Grand Clearance
|
100-150mm
|
|
Tire Size
|
18/8.5-8
|
|
Curb Weight
|
400-500kg
|
|
Dimension
|
3550*1200*1710mm
|
|
Maximum Speed
|
30-50Km/h
|
|
Grade Ability
|
≥25°
|
|
Driving Mileage
|
≥90km
|
|
Standing Postion of Tail Caddie
|
Unequipped
|
|
Seats
|
1 - 2
|
|
Fuel Type
|
Gasoline
|
|
Certification
|
ce, EPA
|
|
Engine Type
|
300CC Single cylinder, vertical,4- stroke, water cool, sohc-4 walve
|
|
Max power(Kw/Rmp)
|
19KW(25.84HP)/6500rmp
|
|
Max Torque(N.m/Rmp)
|
26N.m/6500rmp
|
|
Max Speed
|
45KM/H(adjustable)
|
|
Drivetrain
|
Shaft-driven
|
|
Range
|
300km (loaded 100KG on flat road)
|
|
Fuel Tank
|
12L
|
|
Frame
|
Welded steel with coated twice
|
|
Windscreen
|
Foldable organic glass
|
|
Climbing capability
|
40 degrees (fully loaded)
|
Packing & Delivery
The steel frame is packed with iron wiring for added support.
