- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Frequency Range:
-
698-4200MHz
-
Gain:
-
7dBi/9dBi
-
Polarization:
-
Vertical
-
Application:
-
4G/WIFI Devices/5G Network
-
Connector:
-
N-Female
-
VSWR:
-
1.5MAX
-
Impedance:
-
50ohm
-
Size:
-
165*155*50mm
-
Color:
-
White
-
Keywords:
-
4g 5g panel antenna
Quick Details
-
Type:
-
DAS Antenna
-
Brand Name:
-
XJS
-
Model Number:
-
TDP-0642-9
-
Place of Origin:
-
Guangdong, China
-
Frequency Range:
-
698-4200MHz
-
Gain:
-
7dBi/9dBi
-
Polarization:
-
Vertical
-
Application:
-
4G/WIFI Devices/5G Network
-
Connector:
-
N-Female
-
VSWR:
-
1.5MAX
-
Impedance:
-
50ohm
-
Size:
-
165*155*50mm
-
Color:
-
White
-
Keywords:
-
4g 5g panel antenna
Product Specifications
|
Model
|
TDP-0642-9
|
|
|
|
Frequency Range
|
698~960MHz
|
1710~3800MHz
|
|
|
Gain
|
7 dBi
|
9 dBi
|
|
|
VSWR
|
≤1.5
|
≤1.5
|
|
|
Polarization Type
|
Vertical
|
|
|
|
Input Impedance
|
50Ω
|
|
|
|
Horizontal Beamwidth
|
70°
|
60°
|
|
|
Vertical Beamwidth
|
55°
|
45°
|
|
|
Maximum Power
|
50W
|
|
|
|
Connector Type
|
N-Female
|
|
|
|
Lighting Protection
|
DC Ground
|
|
|
|
Dimension
|
165*155*50mm
|
|
|
|
Weight
|
0.4Kg
|
|
|
|
Rated Wind Velocity
|
140km/h
|
|
|
|
Working Temperature
|
-40℃~+65℃
|
|
|
Applications:
* LPWAN, LoRa, LTE-M, NB-IoT, IoT, M2M applications
* Cellular networks DAS (Distributed Antenna Systems)
* IEEE 802.11b/g WiFi applications
* Public safety
* SOFDMA
* 3.5 GHz Band Applications
* Wireless LAN systems & IEEE 802.11n & 802.16e Application
Features:
* Broad band, Stable performance
* Low VSWR, High gain
* Small size
* LPWAN, LoRa, LTE-M, NB-IoT, IoT, M2M applications
* Cellular networks DAS (Distributed Antenna Systems)
* IEEE 802.11b/g WiFi applications
* Public safety
* SOFDMA
* 3.5 GHz Band Applications
* Wireless LAN systems & IEEE 802.11n & 802.16e Application
Features:
* Broad band, Stable performance
* Low VSWR, High gain
* Small size
