Quick Details
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
6001-14000 kg
-
Drive Wheel:
-
8X4
-
After-sales Service Provided:
-
Onsite Installation, Video technical support, Overseas Call Centers, Return and Replacement, No after-sales service, Field installation, commissioning and training, Online support, Free spare parts, Field maintenance and repair service, Shop warranty
-
Brand Name:
-
HOWO
-
Place of Origin:
-
China
-
Dimensions (L x W x H) (mm):
-
7800x2300x1500mm
-
Cabin Model:
-
HW76
-
Engine Model:
-
WD615.47
-
Rated power:
-
371HP(273Kw/rpm)
-
Displacement:
-
9.726L
-
Wheelbase:
-
1800+4300+1400mm
-
Cargo body size:
-
7800x2300x1500mm
-
Wheel & Types:
-
11.00-20 tube
-
Starter:
-
24V, 5.4KW
-
Alternator:
-
28V, 1540W
-
Batteries:
-
2x12, 165Ah
Quick Details
-
Condition:
-
New
-
Horsepower:
-
371HP
-
Emission Standard:
-
Euro 2
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
6001-14000 kg
-
Drive Wheel:
-
8X4
-
After-sales Service Provided:
-
Onsite Installation, Video technical support, Overseas Call Centers, Return and Replacement, No after-sales service, Field installation, commissioning and training, Online support, Free spare parts, Field maintenance and repair service, Shop warranty
-
Brand Name:
-
HOWO
-
Place of Origin:
-
China
-
Dimensions (L x W x H) (mm):
-
7800x2300x1500mm
-
Cabin Model:
-
HW76
-
Engine Model:
-
WD615.47
-
Rated power:
-
371HP(273Kw/rpm)
-
Displacement:
-
9.726L
-
Wheelbase:
-
1800+4300+1400mm
-
Cargo body size:
-
7800x2300x1500mm
-
Wheel & Types:
-
11.00-20 tube
-
Starter:
-
24V, 5.4KW
-
Alternator:
-
28V, 1540W
-
Batteries:
-
2x12, 165Ah
Product Description
Sinotruk HOWO Dump Truck
Main Features:
HOWO Tipper truck 8×4, Euro Ⅱ, extended cab
Product Parameter
| Typical truck model | ZZ3317N3567A | ZZ3317N3867A | ZZ3317N4347A | ZZ3317N4667A | |
| Cab | Model | HW76 | |||
| Type | HW76 extend cab, one berth, with A/C all-steel forward control, 55°hydraulically tiltable to the front,2-arm windscreen wiper system with 3 speeds, laminate windscreen, with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, heating & ventilation system, adjustable roof flap, with stereo radio/cassette recorder, sun visor, and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorber with transverse stabilizer, safety belt. | ||||
| Engine | Model | WD615.69 | WD615.47 | ||
| Rated power | 336HP(247Kw/rpm) | 371HP(273Kw/rpm) | |||
| Displacement | 9.726L | ||||
| Type | 6 cylinder in-line with water cooling, turbo-charging & inter cooling | ||||
| Wheelbase | 1800+3500+1400mm | 1800+3800+1400mm | 1800+4300+1400mm | 1800+4600+1400mm | |
| Cargo body size | 7000x2300x1500mm | 7300x2300x1500mm | 7800x2300x1500mm | 8500x2300x1500mm | |
| Clutch | Single- plate dry diaphragm spring clutch, diameter 430(C) mm, hydraulically operating with air assistance | ||||
| Transmission | SINOTRUK HW series 10/12/16 speed transmission, 10 forward and 2 reverse | ||||
| Front axle | Steering axle with double T-cross section HF9 | ||||
| Drive axle |
Pressed axle housing, central single reduction HC16/AC16
Ratio: 5.73 |
||||
| Chassis |
Frame: U-profile parallel ladder type with a section of 320×90×8 mm, all cold riveted cross members and reinforced subframe
Front suspension: 9 semi-elliptic leaf springs with hydraulic telescopic double-action shock absorbers and stabilizer Rear suspension: 9+6 semi-elliptic leaf springs with hydraulic telescopic double-action shock absorbers and stabilizer Spare wheel carrier: with one spare wheel Aluminum fuel tank: with 400 L fuel tank with locking fuel cap |
||||
| Steering | Germany brand, hydraulic steering with power assistance | ||||
| Brakes |
Service brake: dual circuit compressed air brake
Parking Brake(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust brake Option: ABS |
||||
| Wheel & Types |
Rims: 8.0-20, 10 hole-steel
Types 11.00-20 tube; Option: 12.00-20 tube, 12.00R20 tube |
||||
| Electrics |
Operating voltage:24V, negative grounded; Starter: 24V, 5.4KW
Alternator: 28V, 1540W; Batteries: 2×12, 165Ah Cigar-lighter, horn, headlamp, fog light, brake lights, indicators, and reverse lamp |
||||
