Quick Details
-
Place of Origin:
-
Shandong, China
-
Voltage:
-
380, 380V
-
Dimension(L*W*H):
-
15*3*2.5m
-
Power (kW):
-
37
-
Weight:
-
200 KG
-
Cooling method:
-
water
-
Processing Type:
-
Extruding
-
Marketing Type:
-
New Product 2022
-
Finished product:
-
EPE net product
-
Keywords:
-
Keywords
Quick Details
-
Screw Design:
-
Single-screw
-
Screw L/D Ratio:
-
55:1
-
Screw Speed (rpm):
-
40 rpm
-
Place of Origin:
-
Shandong, China
-
Voltage:
-
380, 380V
-
Dimension(L*W*H):
-
15*3*2.5m
-
Power (kW):
-
37
-
Weight:
-
200 KG
-
Cooling method:
-
water
-
Processing Type:
-
Extruding
-
Marketing Type:
-
New Product 2022
-
Finished product:
-
EPE net product
-
Keywords:
-
Keywords
Product Description
Parameter
|
Raw material
|
high pressure polyethylene, butane(foaming agent), triglyceride and other additives
|
|
Output
|
15-25 kg/h
0.5-0.6g: about 50,000pcs/h
0.8-0.9g: about 31,250pcs/h
|
|
Screw diameter
|
φ75mm
|
|
Screw L/D
|
55:1（Long type）
|
|
Screw material
|
38CrMoALA
|
|
Production line speed
|
10-60m/min
|
|
Barrel outside diameter
|
φ140mm
|
|
Total power
|
37KW
|
|
Worker
|
2 persons for each shift
|
|
Cooling type
|
by water or air
|
|
Shape Dimension
|
15*3*2.5m
|
Main parts
Extruder
Screw diameter
:
φ75mm
Sc
rew L/D: 55:1
Foam net size: 10-40 mesh
Blowing rate: 20-40
Screw and barrel material: 38CrMoAlA, surface nitrided
Output: 15-25 kg/h
Die
Heating type: stainless steel heating ring
Cooling type: wind cooling
Net type: Shrinkable (Programmable control)
High-speed rotating die
Power: 3kw
frequency control timing
cutter
Power: 0.75KW
frequency control timing
Finished product
