Quick Details
-
Size:
-
4500*3450*1400mm
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Kingsely
-
Power:
-
1.5
-
Product name:
-
Industrial Ironing Machine
-
Ironing width:
-
3300mm
-
Roll Numbers:
-
3-25
-
Ironing speed:
-
3-25 m/min
-
Steam consumption:
-
300/450 kg/h
-
Steam pressure:
-
0.4-0.6 Mpa
-
size:
-
4500*3450*1400mm
-
Motor power:
-
1.5kw
-
Roller material:
-
stainless steel
-
Heating power:
-
129.6kw
Quick Details
-
Warranty:
-
1 Year
-
After-sales Service Provided:
-
Video technical support, Free spare parts, Online support
-
Weight:
-
4000KG
-
Size:
-
4500*3450*1400mm
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Kingsely
-
Power:
-
1.5
-
Product name:
-
Industrial Ironing Machine
-
Ironing width:
-
3300mm
-
Roll Numbers:
-
3-25
-
Ironing speed:
-
3-25 m/min
-
Steam consumption:
-
300/450 kg/h
-
Steam pressure:
-
0.4-0.6 Mpa
-
size:
-
4500*3450*1400mm
-
Motor power:
-
1.5kw
-
Roller material:
-
stainless steel
-
Heating power:
-
129.6kw
Products Description
1.Stainless steel guide cloth shaft, elastic adjustable belt tensioner, Taiwan DSC trap double pressure high more energy saving.
2.Korea LS frequency conversion stepless speed regulation, wide speed range, low energy consumption, low noise, very convenient.
3.The drying cylinder is made of high quality 304 stainless steel with a diameter of 800mm. The surface is specially treated and the linen starch is not easy to stick. Roll thickness 4mm.
Specification
|
|
|
Y2I1-3300
|
YZ11-3300
|
YZIV-3300
|
YZV-3300
|
|
Voltage
|
V/P/Hz
|
220/240/380/415/440
|
220/240/380/415/440
|
220/240/380/415/440
|
220/240/380/415/440
|
|
Roll Numbers
|
|
2
|
3
|
4
|
5
|
|
Roller Diameter
|
mm
|
800
|
800
|
800
|
800
|
|
Max Ironing Width
|
mm
|
3300
|
3300
|
3300
|
3300
|
|
Ironing Speed
|
m/min
|
3-20
|
3-25
|
3-35
|
3-55
|
|
Motor Power
|
Kw
|
1.5
|
1.5
|
2.2
|
3
|
|
Inverter Power
|
Kw
|
1.5
|
1.5
|
2.2
|
3.7
|
|
Electric Heating Power
|
Kw
|
79
|
129.6
|
172.8
|
/
|
|
Electricity Consumption
|
Kw/h
|
0.6
|
0.6
|
1
|
1.2
|
|
Steam Heating Pressure
|
Mpa
|
0.4-0.6
|
0.4-0.6
|
0.4-0.6
|
0.4-0.6
|
|
Max Steam Limited Pressure
|
Mpa
|
0.7
|
0.7
|
0.7
|
0.7
|
|
Steam Consumption
|
kg/h
|
200/300
|
300/450
|
400/550
|
500/600
|
|
Gas Heating Pressure
|
Mpa
|
0.05 -0.08 3
|
0.05 -0.08
|
0.05 -0.08
|
0.05 -0.08
|
|
Gas Consumption
|
m'/h
|
12
|
18
|
24
|
30
|
|
Steam Inlet Pipe
|
mm
|
DN40
|
DN40
|
DN40
|
DN40
|
|
Gas Inlet Pipe
|
mm
|
DN40
|
DN40
|
DN40
|
DN40
|
|
Machine Dimension
|
mm
|
4500*2500*1400
|
4500*3450*1400
|
4500*4400*1400
|
4500*5350*1400
|
|
Machine Weight
|
Kg
|
2600
|
4000
|
5000
|
6300
|
