Model
|
FSM380M-72
|
FSM385M-72
|
FSM390M-72
|
FSM395M-72
|
FSM400M-72
|
||||
|
Nominal Power
|
380W
|
385W
|
390W
|
395W
|
400W
|
||||
|
Maximum Power Voltage(Vmp)
|
40.5V
|
40.8V
|
41.1V
|
41.4V
|
41.7V
|
||||
|
Short-circuit Current(Isc)
|
9.75A
|
9.92A
|
10.12A
|
10.23A
|
10.36A
|
||||
|
Open-circuit Voltage(Voc)
|
48.9V
|
49.1V
|
49.3V
|
49.5V
|
49.8V
|
||||
|
Maximum Power current(Imp)
|
9.39A
|
9.44A
|
9.49A
|
9.55A
|
9.60A
|
||||
|
Module Efficiency(%)
|
19.16%
|
19.42%
|
19.67%
|
19.92%
|
20.17%
|
||||
|
Power Tolerance
|
0~+5W
|
|
|
|
|
||||
|
Maximum System Voltage
|
1000V / 1500V DC(IEC)
|
|
|
|
|
||||
|
Operating Temperature
|
-40 ℃ to 85 ℃
|
|
|
|
|
||||
> Antireflective glass
> Translucency of normal luminance is increased by 2%
> Module efficiency is increased by 2%
> Self-cleaning function
> Service life is as long as 25 years (30 years optional)
> High Efficiency PV Cells
> Appearance Consistency
> Color sorting ensure consistent appearance on each module
> Anti-PID
> Conventional frame
> Silver or black frames are optional
> Boost bearing capability and prolong service life
> Serrated-clip design tensile strength
> Seal-lip designglue injection
> Conventional standalone edition and engineering custom edition
> Quality diode ensures module running safety
> IP67 protection level
> Heat dissipation
> Long service life
|
Payment Terms
|
T/T
|
EXW
|
30% T/T in advance, paid the balance before shipment
|
|
|||
|
|
|
FOB
|
|
|
|||
|
|
|
CFR(C&F)
|
30% T/T in advance, paid the balance against copy of B/L (
Not Suitable for Solar System Orders
)
|
|
|||
|
|
|
CIF
|
|
|
|||
|
|
|
DDP
|
|
|
|||
|
|
L/C
|
L/C amount above 50,000 usd, we can accept L/C at sight (
Not Suitable for Solar System Orders
)
|
|
|
|||
|
|
West Union
|
Amount lower than 5000usd
|
|
|
|||
|
Delivery Time
|
7~10days after receiving payment for one container
|
|
|
|
|||
