Quick Details
-
Lamp Luminous Flux(lm):
-
2600
-
Color Temperature(CCT):
-
6500
-
Place of Origin:
-
Hanoi, Vietnam
-
Brand Name:
-
Rang Dong
-
Model Number:
-
TR100.DC/30W
-
Power (W):
-
30
-
Dimension DxH (mm):
-
100x170
-
Voltage (V):
-
12 & 24 VDC
-
IP:
-
65
-
Luminous efficacy (lm/W):
-
90
-
Lifespan (hrs):
-
20000
-
Beam angle:
-
180
-
CCT (K):
-
6500
Quick Details
-
Warranty(Year):
-
2-Year
-
Light Source:
-
LED
-
Input Voltage(V):
-
12/24 VDC (10,5-28Vdc)
-
Lamp Luminous Flux(lm):
-
2600
-
Color Temperature(CCT):
-
6500
-
Place of Origin:
-
Hanoi, Vietnam
-
Brand Name:
-
Rang Dong
-
Model Number:
-
TR100.DC/30W
-
Power (W):
-
30
-
Dimension DxH (mm):
-
100x170
-
Voltage (V):
-
12 & 24 VDC
-
IP:
-
65
-
Luminous efficacy (lm/W):
-
90
-
Lifespan (hrs):
-
20000
-
Beam angle:
-
180
-
CCT (K):
-
6500
Product Features
- Compatible with 12-volt or 24-volt systems
- High luminous efficacy up to 90 lm/W
- No interference with maritime communication systems
- PBT over moulded aluminium housing with perfect heat dissipation
- PC cover with high lighting transmittance and desired lighting distribution
- IP65
- Long lifespan: 20,000 hours, saving the maintenance cost
Products Details
Product Specifications
|
Model
|
Dimension LxWxH (mm)
|
Power
(W)
|
Voltage (V)
|
Frequency (Hz)
|
Power
Factor
|
Luminous flux
(lm)
|
Luminous efficacy (lm/W)
|
CRI
|
Lifespan
(hrs)
|
|
TR100.DC/30W
|
100x170
|
30
|
12 & 24 VDC
|
2600
|
95
|
6500
|
80
|
3000/4000/5000
|
20,000
|
Customizable:
Power, Voltage, lm/W, CCT (3000/4000/5000/5700/6500K), lifespan, etc.
Luminous Intensity Distribution
Packing and Transportation
|
Type of lamps
|
Quantity in master box (pcs)
|
Estimated quantity/20'DC (pcs)
|
Estimated quantity/40'HC (pcs)
|
|||
|
TR100.DC/30W
|
1
|
15 396
|
35 352
|
|||
|
Customizable according to customer’s request
|
|
|
|
|||
Exported market: South Korea, EU, etc.
