New design high quality metal fence machine palisade fence roll forming machine

New design high quality metal fence machine palisade fence roll forming machine

FOB Reference Price: Get Latest Price

≥1 Sets

US $24500

≥10 Sets

US $21000

≥20 Sets

US $18500

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Rolling thinckness:: 0.3-0.7 mm

Place of Origin:: Fujian, China

Brand Name:: OEM

Voltage:: 380V/50HZ/3Ph or customized

Dimension(L*W*H):: 10800*1600*1600mm

Weight:: 5500 kg

Marketing Type:: Other

Dring Motor:: 7.5Kw

Roller Material:: 45# steel

Shaft Material:: 45# steel

Shaft Diameter:: 75mm

Forming Station:: 18 station

Forming Speed:: 3-5m/min

Machine Frame:: H400

Hydraulic Cutting Motor:: 4KW

Quick Details

Type:: Tile Forming Machine

Tile Type:: Steel

Production Capacity:: Other

Rolling thinckness:: 0.3-0.7 mm

Place of Origin:: Fujian, China

Brand Name:: OEM

Voltage:: 380V/50HZ/3Ph or customized

Dimension(L*W*H):: 10800*1600*1600mm

Weight:: 5500 kg

Marketing Type:: Other

Dring Motor:: 7.5Kw

Roller Material:: 45# steel

Shaft Material:: 45# steel

Shaft Diameter:: 75mm

Forming Station:: 18 station

Forming Speed:: 3-5m/min

Machine Frame:: H400

Hydraulic Cutting Motor:: 4KW

Product Paramenters

Main Driving Motor	7.5KW
Forming Station	18 steps
Roller Material	Cr12
Shaft Diameter	75mm
Shaft Material	45# steel
Feeding Material	1219mm
Machine Frame Type	Stand Pillar
Cutting Type	Hydraulic pressing, hydraulic cutting
Control system	PLC
Main Electric parts	Simenz, Delta, Omron or Schneider
Cutting Length Precision	±2mm
Machine Dimension	105008501450mm
Electric Standard	380V/50HZ/3Ph or customized
Paint Color	Bule+Orange or customized

Products Description

Fast Tile Roof roll forming machine

This color metal fence roll forming machine is with 18 station roll forming, and the covered width after roll forming is
900mm, raw material width is 1220mm aluminum sheet. All the roll forming rollers are made from 45# steel, coated by hard chromed
for enlarge the rollers hardness and can anti rust also. See the encoder supporting rack, it is for installing encoder to measure
fence sheet length and running speed. With manual pre-shear for cutting material head.
