1.Range of use solid wood, embossed plate, carved plate, archaize floor, furniture, table board, handicraft.
2.Conveyor belt,drawing roller,polishing roller by motor,and feeding by frequency conversion.
3.Polishing roller can be easily removed or rearranged.
4.Disc brush have swing device, and each group of disc brush can independently up and down.
5.According the different board texture and model, with diffrent disc brush and polishing rollers.
- Product Details
- {{item.text}}
Quick Details
-
Power (kW):
-
11.65
-
Product name:
-
Wood Brush Polishing Machine
-
Maximum processing width:
-
1000mm
-
Polishing thickness:
-
10-160mm
-
Polishing roller speed:
-
Variable speed FMVariable speed FM
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
HYSEN
-
Weight (KG):
-
2000 KG
-
Power (kW):
-
11.65
-
Product name:
-
Wood Brush Polishing Machine
-
Maximum processing width:
-
1000mm
-
Polishing thickness:
-
10-160mm
-
Polishing roller speed:
-
Variable speed FMVariable speed FM
Product Description
Technical Characteristics:
Specification
|
Model
|
HS1000-4s
|
|
Maximum processing width
|
1000mm
|
|
Polishing thickness
|
10-160mm
|
|
Length of processed plate
|
≥350mm
|
|
Polishing roller speed
|
Variable speed FM
|
|
Belt speed
|
5-20m/min
|
|
Diameter of polishing roller
|
300mm
|
|
Total motor capacity
|
11.65kw
|
|
Straight roller motor
|
2.2kw×2
|
|
Conveying motor
|
1.1kw
|
|
Lifting motor
|
0.55kw-RV40
|
|
Disc motor
|
1.5KW grade 6
|
|
Disk swing motor
|
0.55kw
|
|
Longitudinal roller motor
|
1.5KW grade 6 x2
|
|
Longitudinal roll swing motor
|
0.55kw
|
|
Shipping size
|
3200×1800×1750mm
|
|
Net machine weight
|
2t
|
