Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Asmik
-
Model Number:
-
LUGB-MIK
-
Application:
-
Air, gas, steam
-
Diameter Nominal:
-
DN15 ~ DN300
-
Accuracy:
-
1.0%, 1.5%
-
Ambient Temperature:
-
-40℃-260℃
-
Power Supply:
-
3.6VDC , 24VDC ± 5%
-
Ingress protection:
-
IP65
-
Communication Protocol:
-
RS485, HART optional
-
Output:
-
4-20mA,pulse
-
Connection:
-
Flange Clamp
-
Certification:
-
CE
Quick Details
-
Type:
-
Variable Area Air & Gas Flowmeters, Vortex Flowmeter
-
Material:
-
stainless steel
-
Warranty:
-
12 months
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Asmik
-
Model Number:
-
LUGB-MIK
-
Application:
-
Air, gas, steam
-
Diameter Nominal:
-
DN15 ~ DN300
-
Accuracy:
-
1.0%, 1.5%
-
Ambient Temperature:
-
-40℃-260℃
-
Power Supply:
-
3.6VDC , 24VDC ± 5%
-
Ingress protection:
-
IP65
-
Communication Protocol:
-
RS485, HART optional
-
Output:
-
4-20mA,pulse
-
Connection:
-
Flange Clamp
-
Certification:
-
CE
Products Description
|
Parameters
|
|
|
|
Model
|
SUP-LUGB
|
|
|
Medium
|
Liquid, gas, steam (saturated steam, superheated steam)
|
|
|
Accuracy
|
Gas uncompensated type DN15-DN25--1.5level
|
|
|
|
DN32-DN200--1.0level,
|
|
|
|
DN250-DN300--1.5level
|
|
|
|
Liquid without compensation:DN15-DN300--1.0level
|
|
|
|
Temperature and pressure compensation type:DN25-DN300--1.5level
|
|
|
Medium temperature
|
-40℃-260℃
|
|
|
Output signal
|
Voltage frequency pulse (low level≤1V, high level≥6V)
|
|
|
|
4-20mA output (load resistance≤300Ω)
|
|
|
Communication
|
RS485, HART optional
|
|
|
Table body material
|
stainless steel (other for special customization)
|
|
|
Ingress protection
|
IP65
|
|
|
Power supply
|
lithium battery 3.6VDC, 24VDC ± 5%
|
|
