Quick Details
-
Brand Name:
-
Kingly
-
Model Number:
-
595950
-
Usage:
-
Pipe Clamp
-
Finish:
-
Electrogalvanized
-
Pipe Size:
-
5'' DN125 135-141mm
-
Rod Size:
-
M8, M10
-
Width:
-
23 mm
-
Thickness:
-
2.5 mm
Quick Details
-
Measurement system:
-
INCH, Metric
-
Material:
-
Metal, steel
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Kingly
-
Model Number:
-
595950
-
Usage:
-
Pipe Clamp
-
Finish:
-
Electrogalvanized
-
Pipe Size:
-
5'' DN125 135-141mm
-
Rod Size:
-
M8, M10
-
Width:
-
23 mm
-
Thickness:
-
2.5 mm
Product Description
Product Paramenters
|
Part Number
|
Pipe Size Range(mm)
|
Nut Model
|
Width* Thickness(mm)
|
|
595800
|
12-15
|
M 8 SW13
|
20X1.5
|
|
595810
|
15-19
|
M 8 SW13
|
20X1.5
|
|
595820
|
20-24
|
M 8 SW13
|
20X1.5
|
|
595830
|
25-30
|
M 8 SW13
|
20X1.5
|
|
595840
|
32-37
|
M 8 SW13
|
20X1.5
|
|
595850
|
40-45
|
M 8 SW13
|
20X1.5
|
|
595858
|
44-49
|
M 8 SW13
|
20X2.0
|
|
595851
|
48-53
|
M 8 SW13
|
20X2.0
|
|
595852
|
54-58
|
M 8 SW13
|
20X2.0
|
|
595853
|
59-63
|
M 8 SW13
|
20X2.0
|
|
596460
|
12-15
|
M 8/10 SW13
|
20X1.5
|
|
596470
|
15-19
|
M 8/10 SW13
|
20X1.5
|
|
596480
|
20-24
|
M 8/10 SW13
|
20XL5
|
|
596490
|
25-30
|
M 8/10 SW13
|
20X1.5
|
|
596500
|
32-37
|
M 8/10 SW13
|
20X1.5
|
|
596510
|
40-45
|
M 8/10 SW13
|
20XL5
|
|
595859
|
44-49
|
M 8/10 SW13
|
20X2.0
|
|
595860
|
48-53
|
M 8/10 SW13
|
20X2.0
|
|
595870
|
54-58
|
M 8/10 SW13
|
20X2.0
|
|
595880
|
59-63
|
M 8/10 SW13
|
20X2.0
|
|
595885
|
62-64
|
M 8/10 SW13
|
20X2.0
|
|
596450
|
68-73
|
M 8/10 SW13
|
20X2.0
|
|
595890
|
75-80
|
M 8/10 SW13
|
20X2.0
|
|
595900
|
82-86
|
M 8/10 SW13
|
20X2.0
|
|
595910
|
89-91
|
M 8/10 SW13
|
20X2.0
|
|
595920
|
95-103
|
M 8/10 SW13
|
23X2.5
|
|
595930
|
108-116
|
M 8/10 SW17
|
23X2.5
|
|
595940
|
121-127
|
M 8/10 SW17
|
23X2.5
|
|
595980
|
129-135
|
M 8/10 SW17
|
23X2.5
|
|
595950
|
135-141
|
M 8/10 SW17
|
23X2.5
|
|
595955
|
146-155
|
M 8/10 SW17
|
23X2.5
|
|
595960
|
159-162
|
M 8/10 SW17
|
23X2.5
|
|
595970
|
165-168
|
M 8/10 SW17
|
23X2.5
|
|
595971
|
198-202
|
M 8/10 SW17
|
25X3.0
|
|
595972
|
210-215
|
M 8/10 SW17
|
25X3.0
|
|
595973
|
216-220
|
M 8/10 SW17
|
25X3.0
|
|
595990
|
225
|
M 8/10 SW17
|
30X3.0
|
|
595991
|
250
|
M 0/10 SW17
|
30X3.0
|
|
595992
|
274-280
|
M 8/10 SW17
|
30X3.0
|
|
595993
|
315
|
M 8/10 SW17
|
30X3.0
|
Features
:
*Suitable for Both Indoor and Outdoor Applications.
*Pipe Size Range: 12-315mm.
*Material: Galvanized Steel/EPDM Rubber (RoHs, SGS Certificated).
*Anti-Corrosion, Heat Resistance.
*Fast Delivery Time: Within 35 Days.
*Due to the difference of models, please contact us for more detail
FAQ
1.About Price:
Our prices are mostly based on EXW term with MOQ in normal package without marking. The price is negotiable which can be changed according to your order quantity. When you are making an inquiry, please let us know the quantity you want.
2.About Raw Material:
Galvanized Steel, EPDM rubber (both are RoHs, SGS certificated)
3.About Sample:
Samples are FREE, but please kindly bear the freight costs. We can help to choose the cheapest forwarder service for you. Those costs can be returned when you place the order.
4.About MOQ:
Our MOQ for the products are based on the mould models which can be 3,000pcs to 5,000pcs.
5.About OEM:
Welcome, you can send your own design drawings to us, our R&D Department will give the professional advises and make it into production.
6.About Customized Logo:
Welcome, It will be FREE for you if your order quantity for each size is more than 10,000pcs, please your own design logo CDR file to us.
7.About Quality Control:
QC Department monitors from incoming materials to every important production steps. THREE main testings will be carried out: Salt Spray Test; Torque Test; Tensile Test for loading capacity.
8.About Delivery:
Depends on the products, basically 15-35 working days after prepayment.
9.About Certifications:
ROHS, SGS,FM/UL(on Customer’s brand), we are able to acquire the certifications for your needs.
10.About Payments:
Please kindly note that our payment term is 50% prepayment before production, 50% balance payment before delivery.
