Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
HITBOT
-
Weight:
-
28 kg
-
Dimension(L*W*H):
-
250x250x958mm
-
Power:
-
500W
-
Product name:
-
Servo Motor Robot Arm
-
Model:
-
Z-arm 6142
-
Programming software:
-
HitbotStudio
-
Maximum payload:
-
3KG
-
Maximum reach:
-
400mm
-
Z-axis reach:
-
610mm
-
Repeatability:
-
±0.03mm
-
Connectivity:
-
Wi-Fi/Ethernet
-
Collision detection:
-
Supported
-
Drag to teach:
-
Supported
Quick Details
-
Warranty:
-
1 Year
-
Vertical Travel(mm):
-
610mm
-
Horizonal Travel(mm):
-
400mm
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
HITBOT
-
Weight:
-
28 kg
-
Dimension(L*W*H):
-
250x250x958mm
-
Power:
-
500W
-
Product name:
-
Servo Motor Robot Arm
-
Model:
-
Z-arm 6142
-
Programming software:
-
HitbotStudio
-
Maximum payload:
-
3KG
-
Maximum reach:
-
400mm
-
Z-axis reach:
-
610mm
-
Repeatability:
-
±0.03mm
-
Connectivity:
-
Wi-Fi/Ethernet
-
Collision detection:
-
Supported
-
Drag to teach:
-
Supported
Product Description
Products Description
|
Item
|
Value
|
|
Model Number
|
Z-Arm 6142
|
|
Maximum average linear velocity
|
1255.45mm/s（with 1.5kg payload）
|
|
Repeatability
|
±0.03mm
|
|
Rated payload
|
2kg
|
|
Max payload
|
3kg
|
|
Machine Footprint size
|
200mm*200mm*10mm
|
|
Machine fixing holes spacing size
|
160mm*160mm (with 4 M8*20 screws)
|
|
Voltage
|
220V/110V 50-60HZ DC 24V /Power 500W
|
|
Communication
|
Ethernet
|
|
Customizable Z-axis height
|
0.1-1 meter
|
|
J2 arm travel range
|
Standard: ±164° Optional：15-345°
|
|
Working Environment
|
Temperature: 0-55℃ Humidity: RH85
|
|
Supportable HITBOT Grippers
|
Z-EFG-8/Z-EFG-20/Z-EFG-12 (EFG-100-Optional 485 module)
|
|
Optional accessories
|
Grippers/ 5-th axis /485 board / 3D printing kit
|
|
Digital input（isolated）
|
9+3+arm extensibility for one more arm
|
|
Digital output（isolated）
|
9+3+extensibility for one more arm
|
