Quick Details
-
Place of Origin:
-
Liaoning, China
-
Model Number:
-
70#
-
Brand Name:
-
Dongbei Tegang
-
Surface:
-
black
-
Wire Gauge:
-
1-20mm
Quick Details
-
Steel Grade:
-
70#
-
Type:
-
Drawn Wire
-
Grade:
-
1070
-
Place of Origin:
-
Liaoning, China
-
Model Number:
-
70#
-
Brand Name:
-
Dongbei Tegang
-
Surface:
-
black
-
Wire Gauge:
-
1-20mm
Material: 70#,sae 1070,SWRH72A,SWRh72B,C70 ,CF70,FM70,XC70Steel Wire
Standards:ASTM,JIS,GB,EN(DIN,BS,NF) Or Per as clients ’ requires.
Product Basic Information:
1. Chemical Composition and Mechanical Properties(In Quenched & Tempered State):
|
Chemical Composition |
Mechanical Properties(In Quenched & Tempered State) |
||
|
C |
0.67-0.75 |
Tensile strength(MPA) |
≥715 |
|
Si |
0.17-0.37 |
Yield strength (MPA) |
≥ 420 |
|
Mn |
0.50-0.80 |
Elongation(δ5/%) |
≥ 9 |
|
Cr |
≤0.25 |
Reduction in Area (ψ/%) |
≥ 30 |
|
Ni |
≤ 0.30 |
Impact (J) |
--- |
|
P |
≤ 0.035 |
Hardness |
≤ 269HB(no heat treatment) |
|
S |
≤ 0.035 |
||
|
Cu |
≤ 0.25 |
||
2. Product Application Areas:
O ur products have been used in all kinds of ar e as, such as aviation , aerospace, navigation ,nuclear energy ,chemical
industry, electronic information, achine manufacture, petrochemical, automotive, instrument and meter, Communication ,
transportation, and medical instruments, etc.
3. S imilar steel grade & equivalent steel materials :
|
USA |
Japanese |
Gemany |
British |
France |
International |
Chinese |
|
ASTM&AISI&SAE |
JIS |
EN DIN |
EN BS |
EN NF |
ISO |
GB |
|
1070 |
SWRH72B SWRH72A |
1.0615 |
1.0615 |
1.0615 |
------ |
70# |
Product Sales Information:
|
Size |
Diameter:1.0-20mm Length:in coils |
|
Origin place |
Made In China |
|
Delivery Condition |
Hot rolled,cold drawn |
|
Surface require |
Black,grinding,bright,polish |
|
Heat treatment |
Quenched,Tempered,annealed |
|
Packing |
seaworthy packing ,wooden case ,carton,woven bag or at client's requires |
|
Delivery time |
In 10-50 days |
|
Trade Term |
EXW,FOB,CIF |
|
Payments |
T/T or L/C at sight |
|
Port |
China main Port,such as shanghai,Dalian,Shenzhen port. |
|
MOQ |
1 Ton |
