Quick Details
-
Power (kW):
-
2.2
-
Range of Spindle Speed(r.p.m):
-
0 - 25000 r.p.m
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
fangyuan
-
Voltage:
-
380V 50Hz or selectable
-
Dimension(L*W*H):
-
50*40*85
-
Weight (KG):
-
45 KG
-
Marketing Type:
-
Hot Product 2022
-
Product Name:
-
Chilli sauce Coloidal Sesame Grinder Small Shea Milk Peanut Butter
-
After Warranty Service:
-
Online support
-
Keywords:
-
Chilli sauce Coloidal Sesame mill machine
-
process:
-
custom
-
Certification:
-
CE,ISO9001
-
Capacity:
-
15-18kg/h
-
HS code:
-
84798200
-
Raw material:
-
SUS304/316L
-
Model:
-
JM-50L
Quick Details
-
Output (kg/h):
-
300 - 1000 kg/h
-
Feeding Size (mm):
-
32 - 168 mm
-
Output Size (mesh):
-
300 - 350 mesh
-
Power (kW):
-
2.2
-
Range of Spindle Speed(r.p.m):
-
0 - 25000 r.p.m
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
fangyuan
-
Voltage:
-
380V 50Hz or selectable
-
Dimension(L*W*H):
-
50*40*85
-
Weight (KG):
-
45 KG
-
Marketing Type:
-
Hot Product 2022
-
Product Name:
-
Chilli sauce Coloidal Sesame Grinder Small Shea Milk Peanut Butter
-
After Warranty Service:
-
Online support
-
Keywords:
-
Chilli sauce Coloidal Sesame mill machine
-
process:
-
custom
-
Certification:
-
CE,ISO9001
-
Capacity:
-
15-18kg/h
-
HS code:
-
84798200
-
Raw material:
-
SUS304/316L
-
Model:
-
JM-50L
Chilli sauce Coloidal Sesame Processing Grinding Machine tahini Grinder Small Shea Milk Peanut Butter Make
Main Application:
1. Food industry: Aloe, pineapple, sesame, fruit tea, ice cream, mooncake filling, cream, jam, juice, soybean, bean paste, bean paste, peanut milk, protein milk, soy milk, dairy products, malted milk, flavor, various beverages, etc.
2, chemical industry: paints, pigments, dyes, coatings, lubricants, greases, diesel, petroleum catalysts, emulsified asphalt, adhesives, detergents, plastics, fiberglass, leather, emulsification, etc.
3, daily chemical: toothpaste, detergent, shampoo, shoe polish, high-grade cosmetics, bath essence, soap, balm, etc.
4. Pharmaceutical industry: various syrups, nutritional solutions, proprietary Chinese medicines, poultices, biological products, cod liver oil, pollen, royal jelly, vaccines, various ointments, various oral liquids, injections, intravenous drops, etc.
5, construction industry: all kinds of coatings. Including interior and exterior paint, anti-corrosion and waterproof paint, cold porcelain paint, colorful paint, ceramic glaze and so on.
6, other industries: plastic industry, textile industry, paper industry, coal flotation agent, nanomaterials and other industries high-quality environmental protection production needs.
Working principle :
Colloid mill is driven by the motor through the belt drive gear (or rotor) and the matching fixed teeth (or stator) for relative high-speed rotation, one high-speed rotation, the other stationary, the processed material through its own weight or external pressure (can be produced by the pump) pressure to produce downward spiral impact force, Through the gap between the fixed and rotating teeth (the gap is adjustable), it is subjected to strong shear force, friction force, high-frequency vibration, high-speed vortex and other physical effects, so that the material is effectively emulsified, dispersed, homogenized and crushed to achieve the effect of ultrafine crushing and emulsification of the material.
Technical data :
|
Model
|
|
JM-50L
|
JM-80L
|
JM-100L
|
JM-140L
|
|
|
Emulsification fineness
single loop or multicycle |
300-400
|
2-50
|
2-50
|
2-50
|
2-50
|
|
|
Change range(mm)
|
500-800
|
1-0.01
|
1-0.01
|
1-0.01
|
1-0.01
|
|
|
Production Capacity
(changing with materials) |
1000
|
0.01-0.3
|
3.1
|
35000
|
14*19*39mm
|
|
|
Motor
|
Power(kw)
|
1.1
|
2.2
|
3
|
4
|
|
|
|
Voltage(V)
|
380
|
380
|
380
|
380
|
|
|
|
Rotating speed(r/minjkl)
|
2900
|
2900
|
2900
|
2900
|
|
|
Gringding disc dia.(mm)
|
|
Φ50
|
Φ80
|
Φ100
|
Φ120
|
|
|
Discharge gate dia.(mm)
|
|
Φ15
|
Φ25
|
Φ32
|
Φ40
|
|
|
Feed inlet dia.(mm)
|
|
Φ32
|
Φ50
|
Φ50
|
Φ65
|
|
|
Water-cooling tube dia.(mm)
|
|
Φ1/8"
|
Φ1/4"
|
Φ1/4"
|
Φ1/4"
|
|
|
Overall Dimensions
(L*W*H) |
Length(mm)
|
420
|
520
|
560
|
560
|
|
|
|
Width(mm)
|
280
|
400
|
420
|
420
|
|
|
|
Height(mm)
|
760
|
900
|
950
|
950
|
|
|
Weight(kg)
|
|
45
|
84
|
113
|
135
|
|
Detail picture :
ACHEMA,
Dusseldorf Fair, Germany,
Turkey International Chemical Fair,
Russia International Chemical Exhibition,
Russia International Biotechnology Exhibition.
ACHEMA
Dusseldorf Fair, Germany
Turkey International Chemical Fair
Russia International Chemical Exhibition
Russia International Biotechnology Exhibition
Brazil International Dyestuffs and Chemicals Exhibition
We are online 24 hours a day, please feel free to contact us!
If you want to send inquiry to me about our crusher,could you please tell me?
1) What's your
pre/after-sale service
?
① Professional advice and rich experience help to choose machine.
② Longtime maintainance and considerate technical support
③ Technicians can be sent to abroad to install.
④ One year guarantee. Whole life service. Within 1 year, any problem part can send to us, we can give provide free new part(only damaged by machine itself).
⑤ Any problem before or after delivery, you could find and talk with us anytime. We will free supply technical support.
⑥ Video / CD of test running and installation, Maunal book.
2) How long is your production time?
Our production time is usually 35-40 days. If there is a custom service, the time needs to be calculated separately.
3)
Do you have any certifications qualifying our country?
A: our company’s equipment have passed ISO9001,meanwhile meet the GMP standard with CE & UL certifications, we have exported various countries all over the world, also other certifications is workable if demanded.
