Quick Details
-
Model Number:
-
NE-1KGP
-
Warranty:
-
1years
-
Certification:
-
CE
-
Output Voltage:
-
48V/96V
-
rotor diameter:
-
0.163m
-
Product Name:
-
Vertical Axis Wind Turbine
-
Max Power:
-
1500W
-
Rated Voltage:
-
48V/96V
-
Type:
-
Permanent magnet generator
-
Rated rotated speed:
-
500r/m
-
Top net weight:
-
21kg
-
Output Current:
-
AC
-
Start Torque:
-
0.62Nm
-
Rated Torque:
-
19.1 Nm
Quick Details
-
Rated Power:
-
1KW, 1000W
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Bessent
-
Model Number:
-
NE-1KGP
-
Warranty:
-
1years
-
Certification:
-
CE
-
Output Voltage:
-
48V/96V
-
rotor diameter:
-
0.163m
-
Product Name:
-
Vertical Axis Wind Turbine
-
Max Power:
-
1500W
-
Rated Voltage:
-
48V/96V
-
Type:
-
Permanent magnet generator
-
Rated rotated speed:
-
500r/m
-
Top net weight:
-
21kg
-
Output Current:
-
AC
-
Start Torque:
-
0.62Nm
-
Rated Torque:
-
19.1 Nm
Specification
|
Model
|
NE-1KW
|
|
Rated power
|
1000W
|
|
Maximum power
|
1500W
|
|
Rated voltage
|
48v/96V
|
|
Rated rotated speed
|
500r/m
|
|
Top net weight
|
21kg
|
|
Output Current
|
AC
|
|
Start Torque
|
0.62Nm
|
|
Rated Torque
|
19.1Nm
|
|
Poles
|
12
|
|
Generator
|
Single phase/3 phase permanent magnet synchronous generator
|
|
Insulation Class
|
F
|
|
Service Life
|
More Than 20 years
|
|
Bearing
|
HRB or for your order
|
|
Shaft Material
|
Iron
|
|
Shell Material
|
Aluminum alloy
|
|
Permanent Magnet Material
|
Rare Earth NdFeB
|
|
Protection Grade
|
IP54
|
|
Lubrication
|
Lubrication Grease
|
|
Working temperature
|
-40℃ ~ 80℃
|
