Quick Details
-
WIFI:
-
NO
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
East Asia
-
Model Number:
-
LBD-13
-
AC voltage:
-
AC100V/AC220V±15%
-
Power frequency:
-
50/60Hz
-
Load rated voltage:
-
AC 100V/220V
-
eakage action time:
-
6000 times
Quick Details
-
Rated Voltage:
-
100V/220V
-
Rated Current:
-
10A, 13A, 16A, 20A, < 7A
-
Application:
-
Low-power household appliances,Gas water heater (built-in)
-
WIFI:
-
NO
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
East Asia
-
Model Number:
-
LBD-13
-
AC voltage:
-
AC100V/AC220V±15%
-
Power frequency:
-
50/60Hz
-
Load rated voltage:
-
AC 100V/220V
-
eakage action time:
-
6000 times
| Rated current | AC120V, 50HZ/60HZ |
| Rated voltage | 13A, 15A |
|
Leakage protection current |
When the leakage current is less than or equal to 4mA, no action is required; When the leakage current is greater than or equal to 6mA,it should be operated |
| Action delay |
Leakage current is ≤30mS for 6mA; ≤36.1mS for 204mA; ≤25mS for 264mA; |
| Withstand voltage |
≥1500VAC between the input and output terminals during breakout;≥4000VAC between electrode and housing |
| Withstand surge voltage | 6000V |
| Durability test times | 6000 times |
| Last line number | 16AWG*2C, 17AWG*2C |
| Color | full color |
| Executive Standard | UL943B |
Our factory mainly produces LBD series of creepage protection plugs and sockets including GFCI, ALCI, PRCD and LCDI plugs and sockets. Additionally, we produce AC/DC power adapters. The majority of our products have passed CCC, UL, ETL/CETL and CE certifications. Our products are insured by PICC and our QA program has been closely followed by the National Quality Monitoring and Inspection Bureau for a long time. Due to our strong technical resources, advanced production equipment and strict QC system, our products are now selling well in America, Europe, Southeast Asia and the Middle East. If you require efficient, practical and innovative products, please do not hesitate to contact us today.
Application
1.For SPA leakage protection
2.For hair Dryer leakage protection
3.For washing equipment
4.For heater leakage protection
5.For electric equipment which will use water
