Quick Details
-
Positioning Accuracy (mm):
-
0.01 mm
-
Travel (X Axis)(mm):
-
1300 mm
-
Travel (Y Axis)(mm):
-
2500 mm
-
Repeatability (X/Y/Z) (mm):
-
0.01 mm
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
GoodCut
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
1300*2500*1000mm
-
Power (kW):
-
9
-
Weight (KG):
-
5500
-
Product name:
-
5 axis CNC Router machine with 10 kw spindle for wood engraving
-
Feature:
-
cnc router 5 axis 180° incline carving cutting
-
Working area:
-
1300*2500*1000mm
-
Control system:
-
Taiwan Syntec Controller
-
Spindle power:
-
Italy Spindle
-
Transmission:
-
X/Y/Z ball screw
-
Drive motor:
-
Japan YASKAWA servo motors
-
Table structure:
-
T slot/ vacuum and t slot combined
-
Inverter:
-
Delta Inverter
-
C travelling:
-
0-180°
Quick Details
-
Working Table Size(mm):
-
1300×2500
-
Machine Type:
-
CNC Router
-
Range of Spindle Speed(r.p.m):
-
1 - 24000 rpm
-
Positioning Accuracy (mm):
-
0.01 mm
-
Travel (X Axis)(mm):
-
1300 mm
-
Travel (Y Axis)(mm):
-
2500 mm
-
Repeatability (X/Y/Z) (mm):
-
0.01 mm
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
GoodCut
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
1300*2500*1000mm
-
Power (kW):
-
9
-
Weight (KG):
-
5500
-
Product name:
-
5 axis CNC Router machine with 10 kw spindle for wood engraving
-
Feature:
-
cnc router 5 axis 180° incline carving cutting
-
Working area:
-
1300*2500*1000mm
-
Control system:
-
Taiwan Syntec Controller
-
Spindle power:
-
Italy Spindle
-
Transmission:
-
X/Y/Z ball screw
-
Drive motor:
-
Japan YASKAWA servo motors
-
Table structure:
-
T slot/ vacuum and t slot combined
-
Inverter:
-
Delta Inverter
-
C travelling:
-
0-180°
Good price high quality 5 axis CNC Router machine with 10 kw spindle for wood engraving
* High Z-axis travel, so that very suitable for processing large-scale three-dimensional surface.
* Auto tool change, greatly improve the quality and efficiency.
Standard Configuration of 5 Axis CNC Router:
1.Working size:1300*2500*1000mm, A Axis: ±120°,C Axis: ±213°
2.Taiwan SYNTEC control system
3.Italy HSD 7.0KW air cooling spindle
4.Double pendulum head type HS300
5.Japan YASKAWA servo driver and motor
6.Taiwan HIWIN linear guide
7.Taiwan TBI ball screw for Z axis
8.Japan Shimpo reducer
9.Working voltage:380V,3PH/220V,3PH 50HZ/60HZ
2.Stanard with independent 6 zone matrix vacuum table with high strength. suitable for different size processing.
3.Adopt gantry transmission structure, to ensure fast speed and high efficiency.
4.Adopt Japan THK high precision linear rail with lubrication system, more wearable.
5.Configuration with Japan Yaskawa servo motor, to ensure the transmission stronger and noise lower.
6.Independent control cabinet, spearation of strong electricity and weak electricity to make the maintenance more convenient
7.Taiwan Syntec 60WE control system
8.Italy 9kw HSD ATC spindle.
Parameter
|
Description
|
Parameter
|
|
working area
|
1250x2500mm
|
|
Table structure
|
Weld Steel Movable Table
|
|
Z Structure
|
Taiwan Guide rail: Z #30 Ball screw (3210)
|
|
X, Y Structure
|
Taiwan Guide rail:#40 Ball screw (4040)
|
|
Control system
|
Taiwan Syntec 5 axis control system
|
|
Spindle
|
Italy spindle, water-cooled
|
|
Inverter
|
Delta inverter
|
|
Motor and driver
|
Japan-made YASKAWA
|
|
Reducer
|
Japan SHIMPO
|
|
Command
|
G code
|
Taiwan's Syntec systems
safe and reliable operation, read code speed and efficient, and have online simulation capabilities, online monitoring, to ensure the efficient and safe processing
Japan Yakawa servo motor and driver:
With highly control precision and high speed, reliable and stable;
Taiwan Delta Inverter:
Guarantee the variety working speed and protect the spindle very well;
Japan SHIMPO
Application of High accuracy wooden carving woodworking 5 axis cnc wood router machine:
1. Wood Furniture Industry:
Wave Plate, fine pattern, antique furniture, wooden door, screen, craft sash, composite gates, cupboard doors, interior doors, sofa legs, headboards and so on.
2. Advertising Industry:
Advertising identification, sigh making, Acrylic engraving and cutting, crystal word making, blaster molding, and other advertising materials derivatives making.
3. Die Industry:
A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand, plastic sheeting, PVC pipe, wooden planks and other non-metallic mold.
