- Product Details
- {{item.text}}
Quick Details
-
Dimension:
-
2800x1630x800mm
-
Place of Origin:
-
Zhejiang, China
-
model:
-
ztr
-
condition:
-
new
-
steering:
-
left/right
-
start:
-
electrical starting
-
cooling system:
-
water
-
brand name:
-
Trike Factory
-
brake:
-
disc /disc
-
max speed:
-
120km/h
-
color:
-
red ,yellow ,orange ,white ,green ,blue ,black ,grey
Quick Details
-
Displacement:
-
350CC
-
Brand Name:
-
liqian
-
Tire Size:
-
185/30-R14
-
Dimension:
-
2800x1630x800mm
-
Place of Origin:
-
Zhejiang, China
-
model:
-
ztr
-
condition:
-
new
-
steering:
-
left/right
-
start:
-
electrical starting
-
cooling system:
-
water
-
brand name:
-
Trike Factory
-
brake:
-
disc /disc
-
max speed:
-
120km/h
-
color:
-
red ,yellow ,orange ,white ,green ,blue ,black ,grey
Related Products
Product Description
| 1.Type: | 350CC Water cooled, 4 valve with balance shaft |
| 2.Transmission: | automatic |
| 3.Ignition mode: | CDI |
| 4.Compression propor: | 10.5:1 |
| 5.Power: | 23KW/8,500rpm |
| 6.Max.torque: | 12.7N.m/6,000rpm |
| 7.Displacement: | 350ml |
| 8.Start mode: | electric |
| 9.Tranmission mode: | Shaft drive transmission |
| 10.Min.ground clearance: | 120mm |
| 11.Max.speed: | >120km/h |
| 12.Power source: | 12V,12AH |
| 13.Fuel tank capacity: | 10L |
| Chassis | |
| 1.Front wheels: | 185/30-R14 |
| 2.Rear wheels: | 235/30-R14 |
| 3.Break type(F/R): | disc/disc |
| 4.Front hanging: | double arm-swing |
| 5.Rear hanging: | integral |
| 6.Dimensions | |
| 7.product dimensions: | 2650x1650x770mm |
| 8.carton dimensions: | 2600x1150x750mm |
| 9.wheelbase: | 1450mm |
| 10.height of seats: | 17mm( can be removed front and back) |
| 11.dry weight: | 280kg |
| 12.load capacity: | 230KG |
| 13.climbing degree: | >35 |
| Other | |
| Conveyance: | |
| Qty/20 | 12 |
| Qty/40' | 24 |
| Atv and go kart HS code: | 8703101100 |
