Quick Details
-
Lamp Luminous Efficiency(lm/w):
-
100000
-
Color Rendering Index(Ra):
-
100000
-
Support Dimmer:
-
90
-
Lifespan (hours):
-
100000
-
Working Time (hours):
-
100000
-
Product Weight（kg）:
-
16
-
Input Voltage(V):
-
AC 90-240V, 50-60Hz
-
Lamp Luminous Flux(lm):
-
20000
-
CRI (Ra>):
-
90
-
Working Temperature(℃):
-
-20 - 50
-
Working Lifetime(Hour):
-
100000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
FOR
-
Emitting Color:
-
changeable
-
Name:
-
Animation Laser
-
Other name:
-
5000mW RGB Full Color Moving Head Animation Laser
-
Advantages:
-
3-year long warranty, LED Moving Head Wash + Laser Beam effects
-
Control Mode:
-
ILDA,DMX512,Auto,Sound Active,Master/Slave,SD-Card
-
DMX Channels:
-
27CH
-
Scanner angle:
-
±30°
-
Pan/Tilt:
-
540°/ 270°
-
Scanner:
-
40K high speed module scanner (Can be upgraded to 60K)
-
Dimmer:
-
0-100% linear dimming
-
Warranty:
-
3-year
Quick Details
-
Color Temperature(CCT):
-
6500K
-
Type:
-
LASER LIGHTS
-
Warranty(Year):
-
3-Year
-
Lamp Luminous Efficiency(lm/w):
-
100000
-
Color Rendering Index(Ra):
-
100000
-
Support Dimmer:
-
90
-
Lifespan (hours):
-
100000
-
Working Time (hours):
-
100000
-
Product Weight（kg）:
-
16
-
Input Voltage(V):
-
AC 90-240V, 50-60Hz
-
Lamp Luminous Flux(lm):
-
20000
-
CRI (Ra>):
-
90
-
Working Temperature(℃):
-
-20 - 50
-
Working Lifetime(Hour):
-
100000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
FOR
-
Emitting Color:
-
changeable
-
Name:
-
Animation Laser
-
Other name:
-
5000mW RGB Full Color Moving Head Animation Laser
-
Advantages:
-
3-year long warranty, LED Moving Head Wash + Laser Beam effects
-
Control Mode:
-
ILDA,DMX512,Auto,Sound Active,Master/Slave,SD-Card
-
DMX Channels:
-
27CH
-
Scanner angle:
-
±30°
-
Pan/Tilt:
-
540°/ 270°
-
Scanner:
-
40K high speed module scanner (Can be upgraded to 60K)
-
Dimmer:
-
0-100% linear dimming
-
Warranty:
-
3-year
Laserworld Pro ILDA ISHOW DMX 9*10W LED Movinghead Wash Light & 5000mW 4W 6W 7W RGB Full Color Moving Head Animation Laser
It is a new revolution in moving head lights. It combine the LED Wash,Moving Head and the RGB Colorful Animation Laser. C reates the ultimate visual effect that involves fast moving laser beams and color changes. Suit for Stage,Disco, Clubs, KTV, Pub, Vocal concert,Television Station,Stadium,Advertising promotion etc.
Features of 5000mW RGB Full Color Moving Head Animation Laser:
- Multi-purpose(Moving head+Laser+LED Wash)
- Compatible with ILDA interface and SD card
- Built-in auto and custom programs recalled via DMX,Master/Slave,ILDA
- RGBW color mixing
- High speed scanner
- Electronic zoom function
- LED display with password protection
-
Flicker free on the hight definition camera
- Suit for Pro stage,disco,dj,nightclub,party,ktv and so on
Specifications of 5000mW RGB Full Color Moving Head Animation Laser:
- Laser source: 6W/7W RGB Laser OR 4W/5W RGB Laser
- Laser Wavelength: Red/635nm, Blue/445nm, Green/520nm
- LED source: 9 x 10W RGBW 4-IN-1 LEDs
- LED Beam Angle: 25°/45°
- Operational Modes: DMX512, Sound Active, Auto, Master/Slave,ILDA,SD-Card
- DMX Channels : 27 Channels
- Colors: RGBW LED color mixing + RGB Laser color mixing,more than 1670 million of colors
- DMX Connection: 3-pin OR 5-pin in & out + ILDA in & out
- Scanner: 40K high speed module scanner (Can be upgraded to 60K)
- Scan angle: ±30°;
- Input signal: ±5V;
- Linearity distortion: <2%
- Laser Modulation: Analog
- Beam diameter & Divergence: 5mm & 2mrad
- Patterns: Built-in 144 patterns
- DMX effect: Single pattern modes,and with the function of unique blanking,strobing, rotating, movement, billowing, zoom,drawing,speed and color etc.
- Strobe: Electronic 0-25Hz
- Dimming: Electronic 0-100%
- Zoom: Electronic zoom
- Pan/Tilt: 540°/270°
- Motor: 2pcs of Three-phase 57 stepper motors
- Power Connections: Locking Powercon In
- Power: 200W
- Voltage: AC 90-240V, 50-60Hz
- Weight: 13kg
- Dimensions: 37 x 30 x 56cm
- Approvals: CE,EMC,LVD,RoHS,FCC
Video: https://youtu.be/KtiSPKMQRzo
Cautions
- Dry, less dust, 10~40℃(environmental temperature) ,will reduce the attenuation of the diode and extend the life of the light.
- Be careful with your operations. With a dangerous voltage you can suffer a dangerous electric shock when touching the wires!
- Unplug mains lead before opening the housing!
- To prevent fire or shock hazard,do not expose this fixture to rain or moisture!
- This fixture must be earthed!
- Do no try to repair it when the circuit is out of order, send it back to your supplier to repair!
Pictures of 5000mW RGB Full Color Moving Head Animation Laser:
Here are the Feedback from customers below:
CE,EMC,LVD,RoHS,FCC,CCC,IEC Certificates:
