Quick Details
-
Brand Name:
-
Arcio
-
Model Number:
-
FB1109-1
-
Volume (Litre):
-
5.5-16
-
Gas type:
-
Natual Gas
-
Advantage:
-
Instantance Hot Water
-
Water Pressure Start:
-
0.025 Mpa
-
Ignition:
-
Double Igniters
-
Exhaust way:
-
Flue Exhaust
-
Efficience:
-
84%
Quick Details
-
Warranty:
-
5 years
-
Application:
-
Outdoor, Commercial, Household
-
Place of Origin:
-
China
-
Brand Name:
-
Arcio
-
Model Number:
-
FB1109-1
-
Volume (Litre):
-
5.5-16
-
Gas type:
-
Natual Gas
-
Advantage:
-
Instantance Hot Water
-
Water Pressure Start:
-
0.025 Mpa
-
Ignition:
-
Double Igniters
-
Exhaust way:
-
Flue Exhaust
-
Efficience:
-
84%
Products Description
*The most classic design with full range of capacity
* High efficiency & Energy saving
* Double ignition pin & automatic pulse ignition
*Multi-safety protection devices
* Winter-summer switch option for gas saving
* LED/LCD temperature display optional
* Different panel color /knob available
* Normal & low water pressure system optional
*OEM&ODM solutions provided
* Available in 6L, 7L,8L,10L,12L,14L,16L
Specification
Capacity
|
5.5L
|
6L
|
7L
|
8L
|
10L
|
12L
|
14L
|
16L
|
|||||||
Rated power
|
11KW
|
12KW
|
14KW
|
16KW
|
20KW
|
24KW
|
28KW
|
32KW
|
|||||||
Exhaust type
|
Natrual
|
Flue
|
Flue
|
Flue
|
Flue
|
Flue
|
Flue
|
Flue
|
|||||||
Gas type
|
Natrual gas (NG) or Liquefied petroleum gas (LPG)
|
|
|
|
|
|
|
|
|||||||
Water pressure
|
0.01~0.08Mpa
|
|
|
|
|
|
|
|
|||||||
Efficiency
|
84%
|
|
|
|
|
|
|
|
|||||||
Ignition type
|
Automatic electric pulse ignition
|
|
|
|
|
|
|
|
|||||||
Rated voltage
|
DC 3V
|
|
|
|
|
|
|
|
|||||||
Exhaust pipe size
|
/
|
φ90mm
|
φ108mm
|
φ108mm
|
φ110mm
|
φ110mm
|
φ130mm
|
φ130mm
|
|||||||
Connection size
|
G2/1 or NPT thread
|
|
|
|
|
|
|
|
|||||||
Product dimension (mm)
|
370*290*110
|
440*300*130
|
520*320*168
|
550*328*191
|
610*350*185
|
610*350*185
|
650*400*190
|
680*420*208
|
|||||||
Box dimension
|
460*360*180
|
530*360*180
|
613*383*219
|
643*385*240
|
703*407*240
|
703*407*240
|
800*450*275
|
800*480*275
|
|||||||
Loading qty 20GP
|
1040
|
850
|
550
|
480
|
430
|
430
|
280
|
224
|
|||||||
Loading qty 40HQ
|
2350
|
2080
|
1350
|
1180
|
990
|
990
|
675
|
600
|
Packing & Delivery
1PC/CTN
