Quick Details
-
Max. Loading Capacity:
-
40
-
Weight (KG):
-
2.8 KG
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
HAIJU
-
Voltage:
-
240V/60Hz
-
Dimension(L*W*H):
-
186*83*220mm
-
Power (kW):
-
0.13 kW
-
Timing range:
-
1~9999min
-
Speed display resolution:
-
±1rpm
-
Torque:
-
60N.cm/40N.Cm/80N.Cm
-
Maximum viscosity:
-
50000mPas/10000mPas/80000mPas
-
Drill chuck clamping diameter range:
-
0.5-10mm
-
set:
-
main engine + stainless steel four blade agitator blade + flat bracket
Quick Details
-
Barrel Volume (L):
-
40
-
Max. Loading Volume (L):
-
50 L
-
Range of Spindle Speed(r.p.m):
-
30 - 2200 r.p.m
-
Max. Loading Capacity:
-
40
-
Weight (KG):
-
2.8 KG
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
HAIJU
-
Voltage:
-
240V/60Hz
-
Dimension(L*W*H):
-
186*83*220mm
-
Power (kW):
-
0.13 kW
-
Timing range:
-
1~9999min
-
Speed display resolution:
-
±1rpm
-
Torque:
-
60N.cm/40N.Cm/80N.Cm
-
Maximum viscosity:
-
50000mPas/10000mPas/80000mPas
-
Drill chuck clamping diameter range:
-
0.5-10mm
-
set:
-
main engine + stainless steel four blade agitator blade + flat bracket
|
Product model
|
RWD 50
|
RWD 100
|
RWD 150
|
||
|
Stirring amount L (H, O)
|
20
|
40
|
50
|
||
|
Torque N.cm
|
40
|
60
|
80
|
||
|
Motor input power W
|
60
|
120
|
160
|
||
|
Motor output power W
|
50
|
100
|
150
|
||
|
Weight (kg)
|
2.6
|
2.8
|
3
|
||
|
Power W
|
70
|
130
|
160
|
||
|
Viscosity mPas
|
10000
|
50000
|
80000
|
||
|
Speed range
|
30-2200
|
|
|
||
|
Speed error
|
<± 3rpm
|
|
|
||
|
Motor type
|
Brushless DC motor
|
|
|
||
|
Speed display
|
LCD
|
|
|
||
|
Speed display resolution rpm
|
± 1
|
|
|
||
|
Overload protection
|
Display failure, automatically stop
|
|
|
||
|
Motor protection
|
Display fault, stop automatically
|
|
|
||
|
Drill chuck clamping diameter range mm
|
0.5-10
|
|
|
||
|
Dimensions mm (DX WXH)
|
186x83x220
|
|
|
||
|
Protection method
|
IP42
|
|
|
||
|
Allow ambient temperature ℃
|
5-40
|
|
|
||
|
Allow ambient humidity%
|
80
|
|
|
||
|
RS232
|
Modbus
|
|
|
||
|
Voltage VAC
|
100-240
|
|
|
||
|
Frequency HZ
|
50/60
|
|
|
||
|
Safety protection
|
Chuck protective sleeve safety buckle anti-slip mat
|
|
|
||
|
Mixing time setting
|
Have
|
|
|
||
|
Speed mode
|
Coarse and fine adjustment
|
|
|
||
|
Stirring paddle fixing method
|
Self-locking chuck
|
|
|
||
We pack products by poly bags firstly then by carton case
Delivery Detail : By sea or by courier depend on clients
1.How about packing?
We pack products by film firstly then by carton case
2.How can we get the samples?
The sample is free,but you should pay for the shipping cost.
3.How can I get a price of the goods?
Please tell us your requirement about the material,quality,size,grammage or weight,pattern,etc.
Then we can offer the appropriate price.
4.What about the payment terms?
Our payment term is T/T in advance(30% deposit) or L/C at sight.
