2m PVC Cable
|
|
|
||
|
NPN NO
|
CR30SCF10DNO
|
CR30SCN15DNO
|
||
|
NPN NC
|
CR30SCF10DNC
|
CR30SCN15DNC
|
||
|
NPN NO+NC
|
CR30SCF10DNR
|
CR30SCN15DNR
|
||
|
PNP NO
|
CR30SCF10DPO
|
CR30SCN15DPO
|
||
|
PNP NC
|
CR30SCF10DPC
|
CR30SCN15DPC
|
||
|
PNP NO+NC
|
CR30SCF10DPR
|
CR30SCN15DPR
|
||
|
M12 Connector
|
|
|
||
|
NPN NO
|
CR30SCF10DNO-E2
|
CR30SCN15DNO-E2
|
||
|
NPN NC
|
CR30SCF10DNC-E2
|
CR30SCN15DNC-E2
|
||
|
NPN NO+NC
|
CR30SCF10DNR-E2
|
CR30SCN15DNR-E2
|
||
|
PNP NO
|
CR30SCF10DPO-E2
|
CR30SCN15DPO-E2
|
||
|
PNP NC
|
CR30SCF10DPC-E2
|
CR30SCN15DPC-E2
|
||
|
PNP NO+NC
|
CR30SCF10DPR-E2
|
CR30SCN15DPR-E2
|
||
|
Mounting
|
Flush Non-flush
|
|
Rated distance [Sn]
|
10mm (adjustable)15mm (adjustable)
|
|
Assured distance [Sa]
|
0…8mm 0…12mm
|
|
Dimensions
|
M30*62mm M30*74 mm M30*79mm M30*91 mm
|
|
Output
|
NO/NC(depends on part number)
|
|
Supply voltage
|
10…30 VDC
|
|
Standard target
|
Fe30*30*1t Fe 45*45*1t
|
|
Switch-point drifts [%/Sr]
|
≤±20%
|
|
Hysteresis range [%/Sr]
|
3…20%
|
|
Repeat accuracy [R]
|
≤3%
|
|
Load current
|
≤200mA
|
|
Residual voltage
|
≤2.5V
|
|
Consumption current
|
≤15mA
|
|
Circuit protection
|
Short-circuit, overload and reverse polarity
|
|
Output indicator
|
Yellow LED
|
|
Ambient temperature
|
-25℃…70℃
|
|
Ambient humidity
|
35-95%RH
|
|
Switching frequency [F]
|
50 Hz
|
|
Voltage withstand
|
1000V/AC 50/60Hz 60S
|
|
Insulation resistance
|
≥50MΩ (500VDC)
|
|
Vibration resistance
|
10…50Hz (1.5mm)
|
|
Degree of protection
|
IP67
|
|
Housing material
|
PBT
|
|
Connection type
|
2m PVC cable or M12 connector
|
