54inch Vinyl Cutter MG1200 cutting width 4 feet plotter automatic laser sensor contour sticker cutting machine optical eye plot

54inch Vinyl Cutter MG1200 cutting width 4 feet plotter automatic laser sensor contour sticker cutting machine optical eye plot

FOB Reference Price: Get Latest Price

≥1 Pieces

US $850

≥100 Pieces

US $470

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Brand Name:: MYCUT

Model Number:: MG1200-1

Voltage:: AC110V/220V

Cache Capacity:: 128MB

Cutter Pressure:: 0-500g(optional 0-1000g)

Cutting Speed:: 800mm/s

Driver:: Stepper Motor

Cutting Length:: Unlimited Cutting Plotter

Repeat Cutting:: 1-500 Times

Size:: 1670*330*395mm

laser point:: yes

automatic contour:: ARMS

Interface:: USB2.0/RS232/U-disc

Software:: coreldraw plugin/ signmaster/flexi

Blade:: Roland Blade

Color:: White/pink

Usage:: car sticker, logo cutter

Plotting instruction:: DM-PL HP/GL

Brand:: MYCUT

Quick Details

Paper Feed Width:: 1370mm

Cutting Width:: 1270 mm

Place of Origin:: Guangdong, China

Brand Name:: MYCUT

Model Number:: MG1200-1

Voltage:: AC110V/220V

Cache Capacity:: 128MB

Cutter Pressure:: 0-500g(optional 0-1000g)

Cutting Speed:: 800mm/s

Driver:: Stepper Motor

Cutting Length:: Unlimited Cutting Plotter

Repeat Cutting:: 1-500 Times

Size:: 1670*330*395mm

laser point:: yes

automatic contour:: ARMS

Interface:: USB2.0/RS232/U-disc

Software:: coreldraw plugin/ signmaster/flexi

Blade:: Roland Blade

Color:: White/pink

Usage:: car sticker, logo cutter

Plotting instruction:: DM-PL HP/GL

Brand:: MYCUT

Product Description

MYCUT MG1200 ARMS automatic contour cut signmaster /coreldraw plugin vinyl cutting plotter

Main Features

MYCUT MG Series vinyl cutter with automatic contour cut function. High precision ,fast speed.

1.With laser sensor(contour function),ARMS

2.Real high speed 128MB memory

3.High precision steel roller: guaranteed 5m without deviation of paper feeding

4.High performance 32-bit processor with 256M memory

7.Work with U disc directlly

Model	MG330(12'')	MG630(24'')	MG1200(48'')	MG1500(59'')
Media Way	Desk cutter	Floor Stand	Floor Stand	Floor Stand
Main Board	High-performance & intelligent ARM 32 CPU; 256M memory
Driver	High speed stepping motor, micro-step driver
Max Paper Feed Width	430mm	730mm	1370mm	1600mm
Max Cutting Width	330mm	630mm	1270mm	1500mm
Max Cutting Speed	650mm/s
Cutting Force	0-500g/0-1000g (optional configuration)
Mechanical Precision	0.05mm
Repeatable Precision	< +-0.1mm
Plotter Instruction	DM-PL/HP-GL Automatic Identification
Interfaces	USB / Serial port / U-Disc port
Power Supply	AC110V /220V±10%, 50Hz/60Hz
Software	plugin for coreldraw/signmaster
Noise at Work	≤55DB
External Dimension	750330400mm	1045330400mm	1590330400mm	1890330400mm
Shipping Weight	15kgs	23kgs	33kgs	50kgs

Strong Integrated Carriage

wider range of applications

Integrated Grit Roller

High precision

Big LCD Display

easy-touch silicone keypad with highlight

Strong Pinch Roller

attractive and durable

Three Interfaces

U Disc Port(MH,MG,MS Series only),work without Computer

Standard Blade

Each machine with 1 blade holder,3 blades

MYCUT Vinyl Cutter Performance Video Link

U Disc auto contour cutting(NO need link with Computer!!)
https://www.youtube.com/watch?v=WzRUTo6sPBY&feature=youtu.be

2mm cutting(even 2mm Letter can cut ,so high precision!!)
https://www.youtube.com/watch?v=D1sWWCc7_S4

coreldraw auto contour cutting (Free coreldraw Plug-in, supporting Coreldraw X3-X7 edition!)
https://www.youtube.com/watch?v=LQ3zchv05fE

MYCUT cutting plotter 1cm+3cm circle cutting(Perfect and stable MYCUT Vinyl Cutter!)
https://www.youtube.com/watch?v=SJvdZTqeTaU

MYCUT cutting plotter 5CM circle (high precision to cut the circle)
https://www.youtube.com/watch?v=k9MTgYetpsg

MYCUT cutting plotter 3M Reflective film cutting (High force to cut 3M Refective film!)
https://www.youtube.com/watch?v=nbk0kqpq1j8

Standard Accessories

1) User Manual(CD) 2) 1 RS232 serial cable 3) 1 Power cable and 1 USB cable
4) 3 Cutting Blade 5) 1 Blade Holder 6) 1 drawing pen 7) warranty card

Optional Choices

1)floor stand
2)laser point
3)automatic contour function
4)Signmaster (we supply free coreldraw plug-in)
5)Basket
6)high cutting force
7)U Disc interface(work without computer)
8)bluetooth or wifi wireless transfer
Note:we will extra charge for optional configuration,please contact us for details.

MYCUT Vinyl Cutter Application

Label /Paper Cut

Advertise Sign

Wall / Window Sticker

Heat Transfer

Car Sticker

Packing & Delivery

Standard Packing

With great quality Foam and Carton Packing

Make sure the machine won't be damaged during shipping

Delivery Info

within 7 days for order less than 100 units.

Within 15 days for order more than 100 units.

Factory Info

Shenzhen Huansheng Machinery Co.,Ltd MYCUT Vinyl Cutter Plotter Factor

Shenzhen HuanSheng Machinery Co.,Ltd is a professional manufacturer of vinyl cutter, engraving machine and other CNC equipments.
With the Brand " MYCUT" ,mycut vinyl cutter is new name, but MYCUT team have a long history with more than 10 years in this field. Now MYCUT become the professional supplier of vinyl cutter in China with the highest precision and reliability.We get high reputation from our partners from North America, South Ameraic ,Middle East and Asia.
MYCUT located in Shenzhen ,the "CITY of DESIGN".As a globle supplier for vinyl cutter, we try to offer partners high quality products with fashion design. It's our aim to added value to our customers.

Warranty &Service

1.One year free warranty, main parts are free charge when damaged during the guarantee period.

2.Free training course at our factory with professional engineers.

3.We provide the consumable parts at agent price when you need replacement

4.24 hours online service each day, free online technical support.

5.We provide door to door technical support to agents, if necessary.
