Quick Details
-
Ejection Force(kN):
-
110 kN
-
Ejection Stroke(mm):
-
100 mm
-
Place of Origin:
-
Anhui China (Mainland)
-
Brand Name:
-
longhua
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
6.4*1.7*2.8
-
Year:
-
2024
-
Weight (KG):
-
12000
-
Power (kW):
-
15
-
Clamping Force (kN):
-
2800kN
-
Open Stroke(mm):
-
460mm
-
Space between Tie Bars(mm):
-
560*560
-
Diameter of Bars(mm):
-
100mm
-
Casting Force(kN):
-
330kN
-
Casting Stroke(mm):
-
380mm
-
Casting Pressure(MPa):
-
168MPa
-
After-sales Service Provided:
-
Online support
-
Name:
-
Cold Core Shooting Machine
-
Application:
-
Foundry Industry
-
Molding machine:
-
Foundry Lost Foam Casting Line
-
Certification:
-
CE Certificates
-
Control System:
-
Computer Control
-
Advantage:
-
High Quanlity
-
Color:
-
Custom Made
Quick Details
-
Marketing Type:
-
New Product 2024
-
Max.Thickness of Die Block (mm):
-
650 mm
-
Min.Thickness of Die Block (mm):
-
250 mm
-
Ejection Force(kN):
-
110 kN
-
Ejection Stroke(mm):
-
100 mm
-
Place of Origin:
-
Anhui China (Mainland)
-
Brand Name:
-
longhua
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
6.4*1.7*2.8
-
Year:
-
2024
-
Weight (KG):
-
12000
-
Power (kW):
-
15
-
Clamping Force (kN):
-
2800kN
-
Open Stroke(mm):
-
460mm
-
Space between Tie Bars(mm):
-
560*560
-
Diameter of Bars(mm):
-
100mm
-
Casting Force(kN):
-
330kN
-
Casting Stroke(mm):
-
380mm
-
Casting Pressure(MPa):
-
168MPa
-
After-sales Service Provided:
-
Online support
-
Name:
-
Cold Core Shooting Machine
-
Application:
-
Foundry Industry
-
Molding machine:
-
Foundry Lost Foam Casting Line
-
Certification:
-
CE Certificates
-
Control System:
-
Computer Control
-
Advantage:
-
High Quanlity
-
Color:
-
Custom Made
|
ITEMS
|
Unit
|
Specification
|
|
Clamping Force
|
KN
|
2800
|
|
Opening stroke
|
mm
|
460
|
|
Die thickness(Min--Max)
|
mm
|
250～650
|
|
Space between tie bars
|
mm
|
560*560
|
|
Ejector stroke
|
mm
|
100
|
|
Ejector force
|
KN
|
110
|
|
Injection position（0 as center）
|
mm
|
0，-160
|
|
Injection force（intensification)
|
KN
|
330
|
|
Injection stroke
|
mm
|
380
|
|
Plunger diameter
|
mm
|
￠50 ￠60 ￠70
|
|
lnjection weight(aluminum)
|
Kg
|
3
|
|
Casting pressure (intensification)
|
MPa
|
168/116/85
|
|
Max. casting area(40Mpa)
|
CM2
|
700
|
|
Injection plunger penetration
|
mm
|
140
|
|
Diameter of pressure chamber flange
|
mm
|
110
|
|
Height of pressure chamber flange
|
mm
|
10
|
|
Max.working pressure
|
MPa
|
14
|
|
Motor power
|
Kw
|
15
|
|
Dimensions (L*W*H)
|
m
|
6.4*1.7*2.8
|
|
Machine lifting reference weight
|
T
|
12
|
|
Oil tank capacity
|
L
|
650
|
FAQ
1. who are we?
We are based in Anhui, China, start from 2014,sell to Domestic Market(50.00%),Southeast Asia(15.00%),South Asia(12.00%),South America(8.00%),Eastern Asia(8.00%),Africa(5.00%),Mid East(2.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Die Casting Machine/Robot For Die Casting Machine,Compressor,Die Casting Machine Parts,Mould And Castings,Melting Furnace
4. why should you buy from us not from other suppliers?
Longhua Die Casting Machine has 39 years of production experience, and cooperate with the Chinese Academy of Science and Technology, you know that China's space shuttles are cooperating with the Chinese Academy of Science and Technology.
5. what services can we provide?
Accepted Delivery Terms: FOB；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,Credit Card,Cash;
Language Spoken:English,Chinese
We are based in Anhui, China, start from 2014,sell to Domestic Market(50.00%),Southeast Asia(15.00%),South Asia(12.00%),South America(8.00%),Eastern Asia(8.00%),Africa(5.00%),Mid East(2.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Die Casting Machine/Robot For Die Casting Machine,Compressor,Die Casting Machine Parts,Mould And Castings,Melting Furnace
4. why should you buy from us not from other suppliers?
Longhua Die Casting Machine has 39 years of production experience, and cooperate with the Chinese Academy of Science and Technology, you know that China's space shuttles are cooperating with the Chinese Academy of Science and Technology.
5. what services can we provide?
Accepted Delivery Terms: FOB；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,Credit Card,Cash;
Language Spoken:English,Chinese
