VT200 High performance Silicone rubber Heat Shrink Tube

VT200 High performance Silicone rubber Heat Shrink Tube

FOB Reference Price: Get Latest Price

≥50 Meters

US $0.5

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Material:: Silicone Rubber

Tensile Strength:: 40PSI

Color:: Black.red.yellow.green.blue.can Customized Color

Shrink ratio:: 2:1

Length:: Customized Length

Working temperature:: 40~125 Degrees

Packing:: bag or carton

Thickness:: 0.5mm

Usage:: Sealing

Sample:: Sample Avaliable

Quick Details

Place of Origin:: Jiangsu, China

Brand Name:: Flyron Tech

Model Number:: VT200

Material:: Silicone Rubber

Tensile Strength:: 40PSI

Color:: Black.red.yellow.green.blue.can Customized Color

Shrink ratio:: 2:1

Length:: Customized Length

Working temperature:: 40~125 Degrees

Packing:: bag or carton

Thickness:: 0.5mm

Usage:: Sealing

Sample:: Sample Avaliable

Product Description

Description:

Silicone heat-shrinkable tube
Applications :
Silicone heat-shrinkable tubes are widely used in insulation and protection of household devices,industry equipment , LED cables
and other electronic parts.

Silicone heat-shrinkable tube suitable for any application which high temperature resistance,insulation,corona-resistant,arc
resistance needed,such as the water pipe of hot water machine,coffee maker machine.

Specification

Property	Test Method	Typical Data
Heat shock (275 for 4h)	ASTM D2671	no drop no flow
Tensile strength	ASTM D2671	≥ 6MPa
Break out elongation	ASTM D2671	≥ 200%
Tensile strength after aging(200°C for 168h)	ASTM D2671	≥ 3.5MPa
Break out elongation after aging(200°C for 168h)	ASTM D2671	≥ 150%
Dielectric strength	ASTM D2671	≥ 18kV/mm
Flame retardant	ASTM D2671	Self-extinguish in 60 seconds

Packing & Delivery

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

Ordering information:

specification	Internal diameter （mm）	wall thickness
specification	Internal diameter （mm）			2500v （mm）	4000v （mm）	4000v （mm）	7000v （mm）
φ1.0	1.0±0.10	0.5±0.10	1.00±0.15	1.5±0.20	2.00±0.25
φ2.0	2.0±0.10	0.5±0.10	1.00±0.15	1.5±0.20	2.00±0.25
φ3.0	3.0±0.10	0.5±0.10	1.00±0.15	1.5±0.20	2.00±0.25
φ4.0	4.0±0.10	0.5±0.10	1.00±0.15	1.5±0.20	2.00±0.25
φ5.0	5.0±0.20	0.5±0.10	1.00±0.15	1.5±0.20	2.00±0.25
φ6.0	6.0±0.20	0.5±0.10	1.00±0.15	1.5±0.20	2.00±0.25
φ7.0	7.0±0.20	—	1.00±0.15	1.5±0.20	2.00±0.25
φ8.0	8.0±0.25	—	1.00±0.15	1.5±0.20	2.00±0.25
φ9.0	9.0±0.25	—	1.00±0.15	1.5±0.20	2.00±0.25
φ10.0	10.0±0.25	—	1.00±0.15	1.5±0.20	2.00±0.25
φ11.0	11.0±0.30	—	1.00±0.15	1.5±0.20	2.00±0.25
φ12.0	12.0±0.30	—	1.00±0.15	1.5±0.20	2.00±0.25
φ15.0	15.0±0.30	—	—	1.5±0.20	2.00±0.25
φ20.0	20.0±0.30	—	—	—	2.00±0.3

Technical parameters
Operating temperature			﹣20℃ +200℃
Material			silicone
Fire rating			VW-1
Certification			ROHS
Color			white/red/blue
Cutting tools			Heat gun，oven

FAQ

1. who are we?
We are based in JIangsu, China, start from 2023,sell to Africa(20.00%),North America(10.00%),South America(10.00%),Southeast Asia(10.00%),Mid East(10.00%),Western Europe(10.00%),Central America(10.00%),Northern Europe(10.00%),South Asia(10.00%). There are total about 1-4 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
heat shrink tubing,heat shrink sleeve,medium wall heat shrinki,wrap tape,busbar sleeve

4. why should you buy from us not from other suppliers?
We have a professional service team, professional and responsible. Fast response speed and professional after-sales team.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
