Quick Details
-
Brand Name:
-
KANGYUNSEN
-
Model Number:
-
48V10A
-
Input voltage and current:
-
180-265V
-
output voltage and current:
-
54.6V, 58.4V, 58.8V
-
Maximum Output Power:
-
1200W
-
Place of Origin:
-
Anhui, China
-
Size:
-
220*130*80mm
-
Warranty:
-
1Years
-
Efficiency::
-
≥90%(full Loading)
-
Certificate:
-
CE,ROHS,3C,ISO9000,BIS
-
Ambient temperature:
-
-20℃to50℃
-
Net weight:
-
1,2kg
-
Supports Solar Energy:
-
No
Quick Details
-
Type:
-
Electric, CAR CHARGER
-
Port:
-
DC, AC
-
Material:
-
Aluminum shell, Aluminum shell
-
Brand Name:
-
KANGYUNSEN
-
Model Number:
-
48V10A
-
Input voltage and current:
-
180-265V
-
output voltage and current:
-
54.6V, 58.4V, 58.8V
-
Maximum Output Power:
-
1200W
-
Place of Origin:
-
Anhui, China
-
Size:
-
220*130*80mm
-
Warranty:
-
1Years
-
Efficiency::
-
≥90%(full Loading)
-
Certificate:
-
CE,ROHS,3C,ISO9000,BIS
-
Ambient temperature:
-
-20℃to50℃
-
Net weight:
-
1,2kg
-
Supports Solar Energy:
-
No
|
Product name
|
Lithium battery charger
|
|
Product number
|
48V20A
|
|
Output voltage（V）
|
54.6V/58.4V/58.8V
|
|
Output current （A）
|
20A
|
|
Rated power（W）
|
1200W
|
|
Type:
|
Electric
|
|
Function:
|
AC/DC
|
|
Brand Name:
|
KANGYUNSEN
|
|
Model Number:
|
54.6V20A/58.4V20A/58.8V20A
|
|
size
|
220*130*80mm
|
|
Place of Origin:
|
Anhui,China
|
|
Color:
|
black yellow, blue, green
|
|
Warranty:
|
1Years
|
|
Efficiency:
|
≥90%(full Loading)
|
|
Application:
|
Lithium battery dedicated
|
|
Certificate:
|
CE,ROHS,3C,ISO9000,BIS
|
|
Material:
|
Aluminum shell
|
|
Ambient temperature
|
—20℃to50℃
|
|
Net weight
|
1.8kg
|
|
Is LED Lamp Illumination
|
No
|
|
Supports Solar Energy
|
No
|
Details of functions and features：
1. Intelligent timing to turn the lights 100%: Imported intelligent MCU management chip charges the whole process timing, and the precise algorithm ensures 100% turn lights.
2. Overtime current limit and voltage limit: detect battery charging overtime, force the voltage to be converted to float voltage, and the current is lower than the lamp current to ensure that the battery does not heat up.
3. Grid abnormal protection: the charger will not be damaged if the grid voltage is abnormally high or low.
4. Temperature protection: The output power of the abnormally high temperature charger gradually decreases.
5. Software and hardware start: hardware soft start, plus software soft start to limit the current gradually rise to the maximum.
6. Anti-reverse connection and zero output: the charging polarity does not match, the charger is not damaged, and the charger protects the battery.
7. Temperature compensation: The chip temperature probe can detect the ambient temperature and adjust the output voltage; reduce the voltage in summer to ensure overcharge; increase the voltage in winter to ensure full charge.
8. Balance the battery: Through the special algorithm of the built-in chip, the single backward battery is balanced to extend the battery life.
9. Output protection: built-in imported chip, real-time voltage detection, when an abnormal voltage is detected, the output will be cut off immediately to ensure that the charging voltage is within the set range.
10. LLC resonant circuit: high conversion efficiency, up to 94%, low energy-saving loss.
|
Serial
number
|
Product
number
|
Output voltage（V）
|
Output current （A）
|
Input
power （W）
|
||||
|
1
|
48V8A
|
59V
|
8A
|
500W
|
||||
|
2
|
60V8A
|
74V
|
8A
|
633W
|
||||
|
3
|
72V7A
|
89V
|
7A
|
668W
|
||||
|
4
|
48V10A
|
59V
|
10A
|
627W
|
||||
|
5
|
48V12A
|
59V
|
12A
|
752W
|
||||
|
6
|
48V15A
|
59V
|
15A
|
940W
|
||||
|
7
|
48V18A
|
59V
|
18A
|
1128W
|
||||
|
8
|
60V10A
|
74V
|
10A
|
792W
|
||||
|
9
|
60V12A
|
74V
|
12A
|
950W
|
||||
|
10
|
60V15A
|
74V
|
15A
|
1188W
|
||||
|
11
|
60V18A
|
74V
|
18A
|
1425W
|
||||
|
12
|
72V8A
|
89V
|
8A
|
765W
|
||||
|
13
|
72V10A
|
89V
|
10A
|
957W
|
||||
|
14
|
72V12A
|
89V
|
12A
|
1148W
|
||||
|
15
|
72V15A
|
89V
|
15A
|
1435W
|
||||
|
The benchmark is 25 degrees. The maximum charging voltage of the battery is 14.8V. For example, the 48V battery 14.8V*4=59.2V.
Each time it rises or falls, it reduces or adds 0.09V. And so on.
|
|
|
|
|
||||
Tianchang Sichuang Electronics Co., Ltd. was established in 2000. It is a company specializing in the development of EVchargers, electric bicycle chargers, electric forklift chargers, golf cart chargers, sightseeing car chargers, and scooter chargers. A high-tech enterprise in production and electronic R&D and design, and also a leading enterprise in the industry to develop OCPP AC charging stations.
The company has independently developed basic charging station, RFID up graded charging station, OCPP1.6J commercial charging station and portable mode 2, and is committed to the development and development of high-quality, high-performance and cost-effective charging station.
sichuang business scope covers the world, and it has also established distributors in many countries around the world, including the United Kingdom, Germany, Portugal, New Zealand, Australia, and the United States.
The company's purpose is to bring better products to more people in need.
