Quick Details
-
Scan Speed:
-
300 times/sec
-
Brand Name:
-
YJFIRST
-
Place of Origin:
-
Guangdong, China
-
Product name:
-
2D Barcode Scanner
-
Application:
-
Logistics Industry,door lock,warehouse,hospital
-
Scan Mode:
-
Command Mode/Sense Mode/Auto Reading Mode
-
Decode Capabilities:
-
2D Code and barcode
-
Field of view Angle:
-
Diagonal 70°, 55° horizontal, and 45° vertical
-
Scan the Angle:
-
Turning Angle 360°, Elevation Angle ± 70°, Offset Angle ± 70°
-
LED:
-
White, three directions (front, side, interior)
-
Interface:
-
USB,TYPE-C
-
Scan type:
-
1D/2D/QR Code
-
Keywords:
-
QR Code Barcode Scanner
Quick Details
-
Type:
-
Barcode Scanner
-
Scan Element Type:
-
CMOS
-
Optical Resolution:
-
5mil
-
Scan Speed:
-
300 times/sec
-
Brand Name:
-
YJFIRST
-
Place of Origin:
-
Guangdong, China
-
Product name:
-
2D Barcode Scanner
-
Application:
-
Logistics Industry,door lock,warehouse,hospital
-
Scan Mode:
-
Command Mode/Sense Mode/Auto Reading Mode
-
Decode Capabilities:
-
2D Code and barcode
-
Field of view Angle:
-
Diagonal 70°, 55° horizontal, and 45° vertical
-
Scan the Angle:
-
Turning Angle 360°, Elevation Angle ± 70°, Offset Angle ± 70°
-
LED:
-
White, three directions (front, side, interior)
-
Interface:
-
USB,TYPE-C
-
Scan type:
-
1D/2D/QR Code
-
Keywords:
-
QR Code Barcode Scanner
Products Description
|
Ability to read
|
|
|
||
|
Identification accuracy
|
2 D≥ 5 mil, 1 D ≥4 mil
|
|
||
|
Scan depth of field |
test condition
|
depth of field
|
||
|
|
Code 128 10mil 18bytes Paper copy code
|
0~90mm
|
||
|
|
Code 128 18bytes Mobile phone code
|
0~120mm
|
||
|
|
QR 10mil 160bytes Paper copy code
|
0~55mm
|
||
|
|
DM 15mil 100bytes Paper copy code
|
0~90mm
|
||
|
|
QR 18bytes Mobile phone code
|
0~255mm
|
||
|
Print contrast
|
Minimum 20% of the reflection difference
|
|
||
|
Customer interface
|
|
|
||
|
Trigger way
|
Infrared single induction (default), infrared continuous
|
|
||
|
Prompting mode
|
Buzzer, code reading, NFC, wireless LED indicator, power indicator, horn (custom *)
|
|
||
|
Wired communication interface
|
USB Type C
|
|
||
|
Data wire
|
USB Type C 1.2, m-straight line
|
|
||
|
Supply electricity
|
|
|
||
|
Cell
|
Capacity 2000mAh, available with mobile phone charger 5V 2A, charging time 2h
|
|
||
|
Operate time
|
10 seconds auto-sensing code scanning once, BT transmission to the host computer, working time of not less than 24 hours
|
|
||
|
Dormancy
|
Wake-up time less than 0.1 sec, BT recovery less than 0.1 sec
|
|
||
|
Shut down
|
Shutdown current approx. 500uA
|
|
||
|
Real-time clock
|
Built-in, sweep code can be set up with a time stamp and time retention greater than 5 years
|
|
|
NFC
|
|
|
|
Support agreement
|
ISO/IEC 14443 A ， ISO/IEC 14443 B ，ISO/IEC 15693 ，ISO/IEC 18092
MIFARE and FeliCa ， ISO/IEC 18000-3 / EPC Class-1 HF, ICODE EPC UID / EPC OTP |
|
|
Read distance
|
0~7cm
|
|
|
Enviromental parameter
|
|
|
|
Working temperature
|
-20℃ ~ 70℃
|
|
|
Storage temperature
|
-40℃ ~ 80℃
|
|
|
Humidity
|
Relative humidity: 5% ~ 95% (no condensation)
|
|
|
Ambient light
|
Max.100,000 Lux
|
|
|
Safe
|
|
|
|
Electromagnetic compatibility
|
GB9254-2008 Class B, GB / T17618-2005
|
|
|
Electromagnetic compatibility
|
GB9254-2008 Class B, GB / T17618-2005
|
|
|
Electrostatic protection
|
± 15KV of air, ± 8KV of contact
|
|
|
RoHS
|
consistent with
|
|
|
Safe
|
GB4943.1-2011，GB/T2408
|
|
|
Custom options
|
|
|
|
Add voice, horn
|
Customised quantities from 1000
|
|
