Quick Details
-
Brand Name:
-
HUAIN
-
Model Number:
-
HY-6300A1
-
Certificate:
-
CE RoHS FCC Certificate
-
Application:
-
Conference Room Meeting Solution
-
Color:
-
Black
-
Material:
-
Aluminum Alloy
-
Interface:
-
8-cell Interface Plug
-
Feature:
-
Noise Cancellation
-
Style:
-
Conference Microphone System
-
Microphone:
-
DSP Echo Cancellation
-
Power supply:
-
DC 24V
-
Suitable for:
-
Multimedia Conference Room
Quick Details
-
Type:
-
Audio Conference System, Network Conference System, Video Conference System
-
Function:
-
Translation
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
HUAIN
-
Model Number:
-
HY-6300A1
-
Certificate:
-
CE RoHS FCC Certificate
-
Application:
-
Conference Room Meeting Solution
-
Color:
-
Black
-
Material:
-
Aluminum Alloy
-
Interface:
-
8-cell Interface Plug
-
Feature:
-
Noise Cancellation
-
Style:
-
Conference Microphone System
-
Microphone:
-
DSP Echo Cancellation
-
Power supply:
-
DC 24V
-
Suitable for:
-
Multimedia Conference Room
| Model | Digital conference Chairman /Delegate units |
| frequency response | 30Hz~20KHz |
| Signal to noise ratio | >90dB |
| dynamic range | 96dB |
| Total harmonic distortion | < 0.05% |
| working voltage | 24V DC |
| Working current | 60mA |
| Connector | Large 8-core (or mesh port) |
| Simultaneous opening unit | 6 |
| Color | Black,Blue |
| Video tracking | Yes |
| Conference host language | Chinese,English(customized) |
Features
· 30 conference units can be connected in one way.
· Automatic camera tracking is possible.
· Electret supercardioid directional microphone with pickup distance up to 50-60 cm.
· High end Material,Aluminum alloy panel.
· Connection mode: one line type, junction box, T-head, ring handle.
Conference center control unit
All digital DSP audio processing technology, audio sampling rate up to 48Khz, frequency response up to 20Hz-20KHz.
Features
· Support the connection of 180 microphone units .
· Type of meeting:6 type (First in first out, free discussion mode, speaking mode, queuing mode, computer permission mode and speaking time limited mode)
· Voting function: Yes
· Camera tracking: Yes
· Simultaneous interpretation function: customizable
· Video control: RS-232 interface
· Recording function: USB interface (USB stick)
· The HD video decoding box can automatically switch signals with the HD matrix.
· Language setting: Chinese, English (customized)
